GB-21GB-20
5. A. Replace the bottom door bearing bush
and the limit block.
B. Replace the adjustable foot and place it to
opposite side.
6. A. Replace the bottom hinge, then take off
the bottom door.
B. Fix the bottom hinge with screws to
opposite side.
7. A. Take off the plastic sle ves and mid hinge
keep for later use.
B. Place the bottom door on bottom hinge,
screw the mid hinge to opposite side.
C. Put the plastic sleeves to opposite side.
plastic
sleeves
8. Put the upper door back and put the top-
hinge on.
To Next Page
