REPLACING OVEN LAMP
WARNING: To avoid electric shock, ensure that the appliance circuit is
open before changing the lamp. (having circuit open means power is off)
First disconnect the power of appliance and
ensure that appliance is cold.
Remove the glass protection by turning as
indicated in the gure on the left side. If you
have difculty in turning, then using plastic
gloves will help you in turning.
Then remove the lamp by turning, install the
new lamp with same specications. Lamp
specications must be as follows;
-220V-240V / AC 50Hz, -15 W, -Type G9
Reinstall glass protection, plug the power cable
of appliance into electrical socket and complete
replacement. Now you can use your oven.
CLEANING OVEN GLASS
Figure 13. Simultaneously press the plastic from the left and right
side, gure 14 remove the plastic pulling up.
As shown in gure15, once removed the plastics, glass is totally help-
less. Pull gently to remove the glass. The exterior glass is completely at-
tached to the oven door. After removing the glass, cleaning can be done
easily.
After performing the cleaning and maintenance, please follow the
instructions in reverse to replace the glass and plastics. Make sure the
plastics are in places.
Figure 11
Figure 12
Figure 13 Figure 14 Figure 15
