• If debris cannot be removed easily, remove
retainer clip to access brushroll. Using flathead
screwdriver or coin, turn screw to the ‘unlock’
position.
• Remove retainer clip and lift out brushroll to
clean and remove debris.
To reassemble:
1. Align one end of brushroll with floor nozzle
gear.
2. Press other end into slot.
3. Hook retainer clip under tab and press down.
4. Insert screw and turn to ‘lock’ position.
