Specification
Units available
Represented by
Punted in England
MAINS INPUT
MAINS VARIATION TÔLERATED
LINE REGULATION
Output change for a 10% mains chango
LOAD REGULATION
Output change for a zero to full load change
RIPPLE AND NOISE CONTENT
at full load (\
OUTPUT IMPEDANCE, typical
80kHz)
TRANSIENT RECOVERY TIME, typical
TEMPERATURE COEFFICIENT, typical
OPERATING AMBIENT TEMPERATURE
RANGE for full load current
STORAGE TEMPERATURE RANGE
OVERLOAD PROTECTION
NATO STOCK NUMBERS
MODEL
OUTPUT CURRENT
oUTPUT VOLTAGE d.c.
DIMENSIONS (mm)
WEIGHT (kg)
B30/2
2A
Height 177
Width 134
Depth
5.9
Manutactured in England by
AC. muns 210220 30-240V
105-110 115-12OV. by tap change.
50-400Hz
We reserve the right to amnend specitications without notification
Loss than 0.01%
Less thban 0.02%
Less than 001%
Less than 0.02'%
10%
Loss than 1mV pk-pk
0.12 measurod at 100kHz and 20 C
0.02% per C
Less than 20/4S for output to recover vwithin
50mV following a full load change of 1/4S
rise time
0 to 50 C
-20 C to 85C
B30/10
Constant current limiting on lowost range.
Re-entrant to 10% of Imax. on other ranges.
Input and output fuses.
B30/20
B30/5
5A
177
1mV short term
2mV long term
0-30V, fully variable by 5 position switch
(6V steps) and fine control
134
2mV short term
4mV long torm
281
9.0
6130-99-955-7478
6130-99-618-5353
B30/10
10A
177
160.5
372
14.5
B30/20
20A
177
283
406
25.4
