ALARM CODES:
01 - electronic card alarm
02 - inner ram transducer alarm
04 - outer ram transducer alarm
06 - jib articulating ram transducer alarm
08 - proximity sensor alarm (central one off)
09 - proximity (lateral one off)
10 - mercury sensor level alarm (connector disconnected)
11 - mercury sensor level alarm (sensor defect)
12 - winch alarm
14 - microswitch on the inner ram distributor segment alarm
15 - microswitch on the outer ram distributor segment alarm
16 - microswitch on the jib articulating ram distributor segment alarm
17 - microswitch on the extension rams distributor segment alarm
18 - microswitch on the jib extension rams distributor segment alarm
19 - microswitch on the winch distributor segment alarm
20 - microswitch on the rotation distributor segment alarm
21 - 10A fuse alarm (fuse inside the main control panel protecting
the emergency circuit)
22 - winch stroke end device alarm
Only for crane with slew ring:
30 - inconsistency of the rotation lever movement alarm
31 - inconsistency of the inner ram lever movement alarm
32 - inconsistency of the outer ram lever movement alarm
33 - inconsistency of the crane extension ram lever movement alarm
34 - inconsistency of the jib articulating ram lever movement alarm
35 - inconsistency of the jib extension ram lever movement alarm
36 - inconsistency of the winch lever movement alarm
40 - CAN-BUS reading alarm on unit FX003
41 - CAN-BUS reading alarm on unit FX004
42 - CAN-BUS reading alarm on radio remote receiver unit
MESSAGES EXPLANATION
"WINCH OFF"
- information for the activation of the winch up or down.
"WINCH CAL.ERROR"
- flashing warning (10 seconds each minute); it appears
when the maximum detection of the winch adjustment
with load is exceeded.
"STOP BOOM OUT"
- warning for the interruption of the extension boom exit
because of a sudden variation of the cable tension.
"STOP JIB 25°"
- warning of not permitted activation of the lifting functions
because of the activation of the maximum vertical opera-
tivity of the jib when it is complete with the 25° angle
increasing.
"PLE" - activation of the speed reduction for the use of the
access platform.
