(!) ATTENTION (!)
Activation of the emergency lever.
This activation prevents the operation of the lifting moment limiting device,
consequently, the operation under such conditions can involve an overload
condition. In such an emergency condition (where the lifting moment limiting
device has been disabled), the operator, who is responsible for the machine
safety, must:
-
carefully consider the manoeuvres required to return to normal working
conditions: it is however compulsory to effect the re-entry of the exten-
sion booms at first,
- calmly and carefully assess the type and scale of the hazards arising from
these manoeuvres and the possible reaction of the crane (tipping over,
frame overload, uncontrolled fall of the load due to a hydraulic system
overload etc.);
- make all movements as slowly as possible to reduce the dynamic overload
to the minimum.
After such emergency operations and prior to re-use of the crane, you must
immediately go to FASSI authorised Center for testing the structure and re-sea-
ling of the device.
(!) Interferences with the valves or removal of the lead seal release the
FASSI GRU IDRAULICHE
from any responsibility and invalidate the warranty.
(!) ATTENTION (!)
The presence of the lifting moment limiting device does not release the user
from the obligation to respect what is indicated on capacity plates and lif-
ting curves.
(!) CAUTION DANGER (!)
On the outer boom there is a mercury capsule (mercury level switch) duly protec-
ted and provided with the following warning stickers.
Mercury is extremely toxic. In case of replacement and/or scrapping, dispo-
se of or recycle the capsule containing mercury with maximum care, and in
accordance with the national regulations in force.
(!) ATTENTION (!)
Do not walk on the lever guards of the lifting moment limiting device posi-
tioned on the distributors or electric control panels. DE1679
Do not use water to estinguish fire! DE1680
16.7.3
CONTROLS TO
OPERATE THE CRANE
GR2_45»60_3_4
DE1679
DE1680
