27
24
25
26
20
21
22
23
•
Contrast: set screen contrast from 1-11.
27 To access “Advanced Settings”, hold finger 5
seconds on icon. A warning will appear:
Caution: Incorrect configuration
can damage your system, continue?
YES NO
25
Displays filter usage in days and resets filter timer.
26
Set Screen Options:
•
Daylight Time (ON/OFF): activate only if you are
located in a “Daylight Savings Time” zone.
•
Reverse: Select between dark background (ON)
or light background (OFF)
•
Night Reverse: Select between ON: Automatically
reverses screen background for comfortable
viewing at night (from 9PM to 6AM) OFF: screen
background determined by “Reverse” function
setting.
• You will be prompted to: (first time user) Enter
the default PIN
• Enter your new PIN Re-enter your new PIN
• There are two modes of password protection: Full
Lock and Partial Lock
• The full lock Function does not allow any changes
unless the user enters the PIN
• Partial Lock allows you to change only the
temperature setpoint without entering a PIN.
32 Enter “Installer Message” (up to 42 characters) to
appear at programmable intervals, see 17.
28 Turn “Filter Monitor” ON or OFF; if ON enter the
filter replacement interval.
29 Enter HVAC system consumption parameters
rounded off to kW; see 26 (Typically: Fan 1kW; Heat
Pump 1kW/ton; Furnace 5-30 kW, 7-9¢/kW)
30 Change thermostat temperature display units (ºF or ºC).
31 Turn “Security” ON or OFF (Default Security PIN =
1111) and select the security level: The security
settings allow you to protect your thermostat
thermostat from unauthorized use.
• Turn Security On or Off ( Default pin 1111)
31 32
28 29 30
MENU PAGE
TO ACCESS THE MENU PAGE,
SIMPLY TOUCH
FROM THE CONTROL PAGE.
ADVANCED SETTINGS PAGE 1
To Next Page
