To prepare your machine for use:
a) Remove the packing and protective material. When handling the machine,
two persons should be used. Do not lift from the rail!
b) Check the delivery for any damage incurred during transportation.
Confi rm that the shipment corresponds with the details in the delivery
note. Inform dealer and sender immediately about possible damages or
incomplete shipment.
Each standard package(*) contains:
• One binding machine unit equipped with
• Οne softcover paperguide and
• Οne softcover nipping plate (marked with “S”)
• One power cable
• This User’s Manual
(*) Defi nition of standard package may vary in different countries
c) Select a good location for your machine
• Position the machine on a steady horizontal surface close to a
power outlet
• When selecting the location, remember that the machine weights
52 kg (105 lb)
• For your own convenience, make sure that there is enough
space around the machine for papers, covers and other necessary
supplies.
d) Rotate the turntable to down (DN) position (see the printed scale next
to a operating handle). Open the clamp by pulling the clamp handle and
remove the power cord and possible test books.
e) Remove the reservoir cap and check the glue level in the adhesive
applicator. Hot-melt adhesive should always cover the minimum
level plate. This plate with
multiple holes is visible
when glue has melted and
can be seen from the fi lling
opening. If the glue level
is low, add more hot-melt
to the applicator. Take care
not to overfi ll the adhesive
reservoir. Do not re-use hot
melt drops from the drop
collector tray.
Section 4
SETUP
Initial Check-Up
!
Locating the machine
Preparations
SETUP
MELTED GLUE
IS HOT!
MAX. LEVEL
DO NOT
OVERFILL!
MIN. LEVEL
1 - 5
