FATEK FBe-20MC - System Configuration

FB Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
3
1 System Configuration
The following shows the system configuration where the External Device of Fatek Automation Corporation and
the Display are connected.
Series CPU Link I/F SIO Type
Setting
Example
Cable
Diagram
FBs
*1
FBs-10MA/MC
FBs-14MA/MC
FBs-20MA/MC
FBs-24MA/MC
FBs-32MA/MC
FBs-40MA/MC
FBs-60MA/MC
FBs-20MN
FBs-32MN
FBs-44MN
CPU unit
*2
Port 0 RS232C
Setting
Example 1
(page 9)
Cable
Diagram 1
(page 37)
FBs-CB2 Port 2 RS232C
Setting
Example 2
(page 10)
Cable
Diagram 2
(page 38)
FBs-CB22
Port 1 RS232C
Setting
Example 3
(page 12)
Cable
Diagram 2
(page 38)
Port 2 RS232C
Setting
Example 2
(page 10)
FBs-CB25
Port 1 RS232C
Setting
Example 3
(page 12)
Cable
Diagram 2
(page 38)
Port 2
RS422/485
(2wire)
Setting
Example 4
(page 14)
Cable
Diagram 4
(page 41)
FBs-CB5 Port 2
RS422/485
(2wire)
Setting
Example 4
(page 14)
Cable
Diagram 4
(page 41)
FBs-CB55
Port 1
RS422/485
(2wire)
Setting
Example 5
(page 16)
Cable
Diagram 4
(page 41)
Port 2
RS422/485
(2wire)
Setting
Example 4
(page 14)
FBs-CM22
Port 3 RS232C
Setting
Example 6
(page 18)
Cable
Diagram 3
(page 39)
Port 4 RS232C
Setting
Example 7
(page 20)
FBs-CM25
Port 3 RS232C
Setting
Example 6
(page 18)
Cable
Diagram 3
(page 39)
Port 4
RS422/485
(2wire)
Setting
Example 9
(page 24)
Cable
Diagram 4
(page 41)
