FATEK FBe-20MC - Page 46

FB Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
46
4D)
• 1:1 Connection
• 1:n Connection
Shield
External Device
Terminal block
Signal name
D+
D-
FG
Signal name
SDA
3
RDB
7
TERMTX
9
5
SG
SDB
8
FG
RDA2
D-Sub 9 pin (plug)
Display
Pin
Shell
Display
Terminal resistance: ON
TERMRX1
CA4-ADPONL-01
User-created Cable
Shield
External Device
Terminal block
Signal name
D+
D-
FG
Signal name
SDA
3
RDB
7
TERMTX
9
5
SG
SDB
8
FG
RDA2
D-Sub 9 pin (plug)
Display
Pin
Shell
Display
Terminal resistance: OFF
TERMRX1
CA4-ADPONL-01
User-created Cable
Shield
External Device
Terminal block
Signal name
D+
D-
FG
Terminal resistance: ON
