H1-6
Item Name Model Number Specifications
FBs-7SG1
1 set (8 digits) 7 segment LED display (or 64 Points independent LED) output display module,
16-Pin Header connector
FBs-7SG2
2 set (16 digits) 7 segment LED display (or 128 Points independent LED) output display module,
16-Pin Header connector
Numeric I/O
Expansion
Module
FBs-32DGI
8 set 4 digits (total 32 digits) Thumbwheel switch (or 128 Points independent switch) multiplex input
module, 30-Pin Header connector
FBs-6AD 6 channel, 14 bits analog input module (-10V~0V~+10V or -20mA~0mA~+20mA)
FBs-2DA 2 channel, 14 bits digital output module (-10V~0V~+10V or -20mA~0mA~+20mA)
FBs-4DA 4 channel, 14 bits digital output module (-10V~0V~+10V or -20mA~0mA~+20mA)
Analog
Expansion
Module
FBs-4A2D
4 channel, 14 bits analog input ＋ 2 channel, 14 bits digital output combo analog module
(-10V~0V~+10V or -20mA~0mA~+20mA)
FBs-TC2 2 channel thermocouple temperature input module with 0.1 resolution℃
FBs-TC6 6 channel thermocouple temperature input module with 0.1 resolution℃
FBs-RTD6 6 channel RTD temperature input module with 0.1 resolution℃
FBs-TC16 16 channel thermocouple temperature input module with 0.1 resolution℃
Numeric I/O Module
Temperature
Input
Module
FBs-RTD16 16 channel RTD temperature input module with 0.1 resolution℃
FBs-CM22
2 port RS232 (Port3＋Port4) communication module
FBs-CM55
2 port RS485 (Port3＋Port4) communication module
FBs-CM25
1 port RS232 (Port3)＋1 port RS485 (Port4) communication module
FBs-CM25E
1 port RS232 (Port3)＋1 port RS485 (Port4)＋Ethernet network interface communication module
FBs-CM55E
1 port RS485 (Port3)＋1 port RS485 (Port4)＋Ethernet network interface communication interface
FBs-CM25C
General purpose RS232 RS485 Converter with optical isolation
FBs-CM5R
General purpose RS485 Repeater with optical isolation
Communication
Expansion
Module
FBs-CM5H
General purpose 4-port RS485 HUB with optical isolation
FBs-CB2
1 port RS232 (Port2) communication board
FBs-CB22
2 port RS232 (Port1＋Port2) communication board
FBs-CB5
1 port RS485 (Port2) communication board
FBs-CB55
2 port RS485 (Port1＋Port2) communication board
FBs-CB25
1 port RS232 (Port1)＋1 port RS485 (Port2) communication board
Communication
Expansion
Board
FBs-CBE
1 port Ethernet communication board
FBs-232P0-9F-150
FBs-Main unit Port0 RS232 to 9Pin female D-Sub communication cable, 150cm long
FBs-232P0-9M-400
FBs-Main unit Port0 RS232 to 9Pin male D-Sub communication cable, 400cm long
Communication
Cable
FBs-USBP0-180
FBs-Main unit Port0 USB communication cable (standard USB A B)
Memory Pack
FBs-PACK
FBs-PLC Program memory pack with 20Kword program, 20Kword register, and write protection
switch
FP-07C
Hand held programmer for FBs-PLC
Programming
Device
WinProladder
WinProladder Programming software for Windows
FATEK Comm. Serve
r
FATEK DDE communication server
FBS-XTNR
Extension cable adapter
Others
HD30-22AWG-200
Include 22AWG I/O cable for 30Pin Header connector, 200cm long ( for FBs-24EX, -24EYT, and
-32DGI)
DBAN.8(DBAN.8LEDR) 0.8〝×4 16 segment display board (with red LED installed )
DBAN2.3(DBAN2.3LEDR) 2.3〝×4 16 segment display board (with red LED installed )
DB.56 (DB.56LEDR) 0.56〝 ×8 7 segment display board (with red LED installed)
DB.8 (DB.8LEDR) 0.8〝×8 7 segment display board (with red LED installed)
DB2.3 (DB2.3LEDR) 2.3〝 ×8 7 segment display board (with red LED installed)
16/7 Segment
LED
Display Board
DB4.0 (DB4.0LEDR) 4.0〝 ×4 7 segment display board (with red LED installed)
FB-DAP-B(R)
16×2 LCD character display, 20key keyboard, 24VDC power supply, RS-485 communication
interface (suffixed R means wireless read card module included)
Simple People
Human Machi-
-ne Interface
FB-DAP-C(R)
16×2 LCD character display, 20key keyboard, 5VDC power supply, RS232 communication interface
(suffixed R means wireless read card module included)
CARD-1
Read-only wireless card (for FB-DAP-BR/CR)
RFID Card
CARD-2
Read/Write wireless card(for FB-DAP-BR/CR)
Education and
Training Kit
FBs-TBOX
46cm × 32cm × 16cm suitcase, containing FBs-24MCT main unit, FBs-CM25E communication
module (RS232 ＋RS485＋Ethernet network), 14 simulated input switches, 10 external relay
isolation output, Doctor terminal outlet I/O, peripherals such as stepping motor, encoder, 7 segment
display, 10 of 10ψLED indicator, thumbwheel switch, and 16key keyboard.
1. □：Blank－relay output，T－transistor output，S－TRIAC output
2. ◇：Blank－Sink（NPN），J－Source（PNP）
3. Δ：Blank－built-in RS232 port，U－built-in USB port
4. ◎：Blank－100~240VAC power supply， D－24VDC power supply
5. Specifications are subject to changes without further notice.
6. XY：(optional),The expanding 120KHz inputs(X) and output(Y), there
are 1~6 Points can be expanded for both X,Y.
Example:FBs-24MCT-21,Its means expanding 2 points of 120KHz
input(total 4 points) and 1 point of 120 KHz output(total 3 points).
And FB
S-24MCT-02 means only expanding 2 points of 120KHz
output(total 4 points).
