1.5 Specifications of Main Unit
Item Specification Note
Execution Speed 0.33uS／per Sequence Command
Space of Control Program 20K Words
Program Memory FLASH ROM or SRAM＋Lithium battery for Back-up
Sequence Command 36
Application Command 300 (113 types) Include Derived Commands
Flow Chart (SFC) Command 4
X Output Contact(DI) X0～X255 (256)
Corresponding to External Digital Input
Point
Y Output Relay(DO) Y0～Y255 (256)
Corresponding to External Digital Output
Point
TR Temporary Relay TR0～TR39 (40)
M0～M799 (800)*
Can be configured as retentive type
Non-retentive
M1400～M1911 (512)
Internal Relay
Retentive M800～M1399 (600)* Can be configured as non-retentive type
M
Special Relay M1912～M2001 (90)
Non-retentive S0～S499 (500)*
S20~S499 can be configured as
retentive type
S Step Relay
Retentive S500～S999 (500)* Can be configured as non-retentive type
T Timer ”Time Up” Status Contact T0～T255 (256)
Single Point
《
BIT Status
》
C Counter ”Count Up” Status Contact C0～C255 (256)
0.01S Time base T0～T49 (50)*
0.1S Time base T50～T199 (150)*
TMR
Current
Time
Value
Register
1STime base T200～T255 (56)*
T0 ~ T255 Numbers for each time base
can be flexibly adjusted.
Retentive C0～C139 (140)* Can be configured as non-retentive type
Non-retentive C140～C199 (60)* Can be configured as retentive type
Retentive C200～C239 (40)* Can be configured as non-retentive type
CTR
Current
Counter
Value
Register
32-Bit
Non-retentive C240～C255 (16)* Can be configured as retentive type
R0～R2999 (3000)* Can be configured as non-retentive type
Retentive
D0～D3999 (4000)
HR
DR
Non-retentive R3000～R3839 (840)* Can be configured as retentive type
Retentive R5000～R8071 (3072)*
When not configured as ROR, it can
serve as normal register (for read/Write)
Read-only
Register
R5000～R8071 can be configured as ROR,
default setting is (0)*
ROR is stored in special ROR area and
not consume program space
HR
ROR
Data Register
File Register F0～F8191 (8192)*
Must save/retrieved via special
commands
IR Input register R3840～R3903 (64) Corresponding to external numeric input
OR Output Register R3904～R3967 (64)
Corresponding to external numeric
output
SR Special System Register R3968～R4167 (197) R4000～R4095 (96) Except R4152～4154
0.1mSHigh Speed Timer register R4152～R4154 (3)
Hardware(4 sets) DR4096～DR4110 (4×4)
High Speed
Counter
Register
Software (4 sets) DR4112～DR4126 (4×4)
R4128 (sec)
R4128
(min)
R4130
(hour)
R4131 (day)
〈
Special Register
〉
Real Time Calendar Register
R4132
(month)
R4133
(year)
R4134
(week)
Not available in MA model
Register
《
WORD Data
》
XR Index Register V、Z (2), P0～P9 (10)
External Interrupt Control 32 (16 point input positive/negative edges)
Interrupt
Control
Internal Interrupt Control 8 (1, 2 3, 4, 5, 10, 50, 100mS)
0.1mS High Speed Timer (HST) 1 (16bits), 4 (32bits, derived from HHSC)
“*” Default Settings
16-Bit
