140
P5043S/P5043N/P5070VS/P5102VS
HMI COM2 Port
PLC RS485 Port
1 DATA+
1 DATA+
6 DATA-
2 DATA-
5 GND
5 GND
Wiring Diagrams:P5043S/P5043N/P5070VS/P5102VS
MODBUS TCP
2.6.2.1 Communication Setting
Item
Default Setting
Remark
