FATEK P5043N - Page 172

172
*Looking into HMI
PIN#
COM2 (RS485)
1
DATA+
2
3
4
5
GND
6
DATA-
7
8
9
HMI COM3 Pinout
*Looking into HMI Device
PIN#
COM3
(RS-422/RS-485)
1
2
3
ISO_GND
4
5
6
DATA+
7
DATA-
P5070S/P5070N/P5070N1/P5102N/P5102N1
HMI COM3 Port
PLC RS485 Port
6 DATA+
12 DATA+
7 DATA-
11 DATA-
