FGP฀50/M฀EVO
Fig. 5 Burner฀signal฀description฀
LEGEND
1)ON/OFF฀button
2)Reset฀from฀lockout฀button฀+฀status฀lamp
BURNER฀SIGNAL฀DESCRIPTION
In฀the฀picture฀below฀there฀are฀indicated฀all฀the฀signalation฀present฀on฀the฀burner:
12
LIGHT-OIL฀BURNERS฀TWO฀STAGES฀PROGRESSIVE฀
OR฀MODULATING
Themulticolorsignallampinthelockoutresetbutton(pos.2)isthekeyindicatingelementforvisualdiagnostics
andinterfacediagnostics.
Innormaloperation,thedifferentoperatingstatesareindicatedintheformofcolorcodes;pleasereferto
electricaldevicehandbooksuppliedwiththepresentinstructions.
Afteranon-alterablelockout,theredsignallampinthelockoutresetbutton(pos.2)lightsup.
Bypressingthelockoutresetbutton(pos.2)formorethan3seconds,thevisualdiagnosticsofthecauseoffault
canbeactivated;pleaserefertoelectricaldevicehandbooksuppliedwiththepresentinstructions.
Forclosethediagnosticsmodeandforswitchontheburneragain,itisnecessarytoresettheburnercontrol.
Pressthelockoutresetbutton(pos.2)forabout1second(<3seconds).
Afteranon-alterablelockout,theredsignallampinthelockoutresetbutton(pos.2)lightsup.
Forresetthecontrolboxpressthelockoutresetbutton(pos.2)forabout1second(<3seconds).
