INTRODUCTION

Appearance and Key Descriptions

Serial

No.

Name

Application

①

Main

Testing

Cable

Connection interface connects

vehicle communication cable

during the vehicle diagnosis.

②

SD Card

Installation interface of SD card

(vehicle testing diagnosis software

is installed in the SD card)

③

USB Port

Use to connect an external printer

(spare).
