Febco 805YD - Spring Removal Tool; Seat Ring Tool

"C" DIA
2PL'S
1" DIA
1/2" STEEL PLATE (MIN)
"D" TREAD
THREADED ROD (STEEL)
"B""B"
"A"
"E"
2 1/4" (MIN)
"E" DIA THRU
"A" STD WT. PIPE (STEEL)
"C" MILLED NOTCH
"C" X "C" SQ - 120º APART
3 PLACES
"B"
"D"
SEAT RING TOOL
SPRING REMOVAL TOOL
NOTE: This information is provided to
expedite servicing of FEBCO products.
One tool may be fabricated for use on
all required sizes by drilling all holes at
appropriate dimensions in a single steel
plate of maximum required length.
CAUTION: To avoid possible injury
during use, do not fabricate tool from
lesser strength material or to smaller
dimensions than minimums shown.
SPRING REMOVAL TOOL DIMENSIONS
Size A B C D E
4" 9
1
/
2
4
1
/
4
5
/
8
1
/
2 –
13 5
1
/
2
6" 12
1
/
2
5
5
/
8
3
/
4
5
/
8 –
11 5
1
/
2
8" 14
1
/
4
6
3
/
8
7
/
8
3
/
4 –
10 7
10" 16
1
/
2
7
1
/
2
7
/
8
3
/
4 –
10 7
SEAT RING TOOL DIMENSIONS
Size A B C D E
2
1
/
2
"2
1
/
2
8
1
/
2
11
3" 3 8
1
/ 5 11
4" 4 9
1
/
2
11
6" 6 10
5
/ 8 11
8" 8 12
5
/
8
11
10" 10 15
5
/ 8 11
Page 5 FEBCO Model 805YD & 806YD (2
1
/
2
" - 10")
