*2: With each of the output items (besides “Spindle No.,” “Parameter No.,” “Spindle Judgment,”
“Spindle Cycle Count (8 digits • 4 digits),” “Tool Cycle Count (8 digits • 4 digits),” and “Load
rate”), the results are output in the order of: indication up to a maximum of 6 digits (without the
decimal point) in 2 words (4 bytes), sign, and number of digits to the right of the decimal point.
12 34 56 0 2
①②
① Sign ② Number of Digits to the right of the Decimal Point
Indication Details Indication Details
0
+ value 0
No digits right of decimal point
1
- value 1
1 digit right of the decimal point
2
2 digits right of the decimal point
3
3 digits right of the decimal point
4
4 digits right of the decimal point
5
5 digits right of the decimal point
*3: With each of “Spindle Cycle Count (4 digits)” and “Tool Cycle Count (4 digits),” numerical values of
the millions, hundred thousands, ten thousands, and thousands places are output as 4-digit BCD
data.
When the cycle count reaches 9,999,999 (99 99BCD), the next cycle will be 10,000,000, output as (00
00BCD).
