Ethernet-I/P Fieldbus Expansion Unit
PAGE 23
● Message Information Output Example (Multi Format)
(Note:PLC output ref. for Allen Bradley)
Multi Format
Output Item Result Output PLC Input (BCD Format)
PLC Input (ASCII Format)
Sequence
Cycle Count
216
C00 00 00
C00 to
C07
‘_____216’
C01 02 16
Date 2013-06-21
C02 20 13 C08 to
C17
‘2013-06-21’
C03 06 21
Time 10:23:36
C04 10 23
C18 to
C25
‘10:23:36’
C05 36 00
Sequence Judgment REJECT C06 00 01
C26 to
C29
‘REJ_’
Sequence No. 1 C07 00 01
C30 to
C31
‘_1’
~
~
~
~
~
Final Message Information
Area
(when 250 bytes are set)
C124 C124
* (20H) is the space code (space).
