34
32
30
28
26
24
22
20
18
16
14
12
10
8
60 70 80 90 100 110
OUTDOOR TEMPERATURE °F
COOLING MODE
26
24
22
20
18
16
14
12
10
8
6
4
2
0
10 20 30 40 50 60
OUTDOOR TEMPERATURE °F
HEATING MODE
UPPER CURVE AT 80 DB, 67 WB (°F) ENTERING INDOOR TEMP.
LOWER CURVE AT 70 DB, 60 WB (°F) ENTERING INDOOR TEMP.
NOTE: All values are for reference only and may vary up or down.
All heating values are with frost-free outdoor coil.
When the outdoor temperature is below 40°F, manually defrost the unit before reading.
18
16
14
12
10
60 70 80 90 100 110
OUTDOOR TEMPERATURE °F
COOLING MODE
26
24
22
20
18
16
14
12
10
10 20 30 40 50 60
OUTDOOR TEMPERATURE °F
HEATING MODE
NOTE: All values are for reference only and may vary up or down.
All heating values are with frost-free outdoor coil.
When the outdoor temperature is below 40°F, manually defrost the unit before reading.
SUPERHEAT CHARGING CHARTS FOR UNITS WITH PISTONS
SUBCOOLING CHARTS FOR UNITS WITH THERMOSTATIC EXPANSION VALVES
