Federal EIMSS60 - Electrical Data

IMSS E3265
-
28
-
ELECTRICAL DATA
Model IMSS60SC/IMSS84SC IMSS60R/IMSS84R
Power Supply, Volts 230 Volts 230 Volts
Frequency 60 Hertz 60 Hertz
Phase 1 Phase 1 Phase
Number of Wires 2 + GND 2 + GND
AMPS VOLTS AMPS VOLTS
Compressor 12.6/12.0 230 - -
Condenser Fan .8 230 - -
Base Fan - - .15 230
Evaporator Fan Motor (QTY 2 or 4) 0.15 ea. 230 0.15 ea. 230
Lights Power Supply 24V .8 230 .8 230
Condensate Pan Heater 7.8 230 - -
Condensate Pump - - .75 230
Refer to the rating plate data attached to side of base for Maximum Fuse Size and
Minimum Circuit Ampacity.
Model IMSS120SC IMSS120R
Power Supply, Volts 230 Volts 230 Volts
Frequency 60 Hertz 60 Hertz
Phase 1 Phase 1 Phase
Number of Wires 2 + GND 2 + GND
AMPS VOLTS AMPS VOLTS
Compressor 12 230 - -
Condenser Fan (QTY 2) .5 ea 230 - -
Evaporator Fan Motor (QTY 6) 0.15 ea. 230 0.15 ea. 230
Lights Power Supply 24V (QTY 2) 1.6 230 1.6 230
Condensate Pan Heater 9.0 230 - -
Condensate Pump - - .75 230
Refer to the rating plate data attached to side of base for Maximum Fuse Size and
Minimum Circuit Ampacity.
