3. Operation
4. Harness belt
Warning
Child harness belts should be adjusted according to the child’s body size.
Incorrect adjustment may cause insufficient effect of child seat followed by fatal injury
at the time of collision.
(1) Adjusting the length of the belt
As a guideline for adjustment, it is ideal to leave the gap that can allow an adult’s palm in between
the child’s body and the shoulder belt
To extend the length of child belt (after placing child): Press the belt length adjustment
lever as shown in the picture ① and pull the shoulder belt forward as shown in the picture ②.
To shorten the length of child belt (after placing the child): Pull the adjusting belt as shown
in the picture ③.
