3. Operation
6. Separation for use in Junior Mode
Release the harness strap combining device on the back of child seat as shown in the picture ①,
and separate the right and left straps from the connecting metal yoke at the lower side.
Pull out the separated harness straps through the front side of the child seat and pull the shoulder pad
as shown in the picture ②.
Completely separate the crotch strap cover from the front of the car seat as shown in the picture ③.
7. Separation for use in the Booster Mode
