FeelTech
FY6600 Series User’s Manual 19
Set Offset
Press OFFS button to highlight offset value. Then use Arrows button and
ADJ Knob to set the value. Press Arrows button to move the cursor and rotate
ADJ Knob to set the value.
The offset accuracy is 1mV. i.e. 0.001V.
When frequency output is lower than 20MHz, the offset can be adjusted
during -10V~+10V.
When frequency output is higher than 20MHz, the offset can be adjusted
during -2.5V~+2.5V.
