Feelworld USB10X User Manual

7
Chapter 2 Install Your Product
2.1 Camera Interface Explanation
Product Interfaces
1. Camera Lens
5. Screw Hole for Tripod
9. USB 2.0 Interface
2. Remote Control Receiving
Indicator
6. RS232 Control Interface
（
Input
）
10. DC12V Input Power Supply
Socket
3. Camera Base
7. RS232 Control Interface
（
Output
）
4. Tripod Screw Hole
8. RS485 Input (left +, right-)
2.1.1 External Interface
Wiring Diagram

Feelworld USB10X Specifications

General

Brand	Feelworld
Model	USB10X
Category	Security Camera
Language	English
