FMT 250; FMT 250Q; FMT 250QSL
4. Tools required
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Standard tools
Special tools
Vice Drawing-off socket cap 6 41 04 150 00 8
Arbor press Chuck cone, 16mm 6 41 07 016 00 1
Plastic hammer Chuck cone, 19mm 6 41 07 019 00 7
Circlip pliers Chuck cone, 26mm 6 41 07 026 00 0
Screwdrivers: Torx 15, Torx 20 Extractor tool
• Thread ring
• Chuck cone
• Screw
• Bolt
6 41 14 031 03 0
6 41 14 031 01 0
6 41 07 013 02 1
6 41 07 013 03 7
Flat-nose pliers
Ball bearing support, 16mm
Ball bearing support, 19mm
Ball bearing support, 26mm
Hot air gun Clamping screw 6 41 07 013 02 1
Punch 5mm, 6mm Press-in fixture 6 41 22 108 00 0
Cross-tip screwdriver (small) Assembly aid 6 41 22 121 01 0
