FRT: KBM 32 Q
5.4. Assembling drill rig
1. Screw the gear rod onto the motor guide
2. Assemble bearing and pressure plate onto the case stand
3. Assemble motor guide and drive shaft
4. Attach magnetic foot to the case stand - threaded bores (arrow) for
the swarf guard always on the motor side
Tools:
- Screwdriver
phillips PH 2, slotted
- Hexagon socket wrench
Ø 3 and 4 mm
- box nut 13 mm
