FRT: KBM 32 Q
3.2. Test data
Nominal voltage 220 - 240 V 110 V / 120 V
Test voltage / 2 % Nominal voltage
No-load current / 10 % (1,44-1,76A) 1,6 A 3 A
No-load speed / 10% (486 - 594 U/min) 540 U/min
Main switch on
Voltage at X7,X8 10% (90-110V/DC) 100 V / DC 50 V / DC
Current consumption 0,15 A 0,25 A
Main switch on, motor on
Voltage at X7,X8 10% (180-220V/DC) 200 V / DC 100 V / DC
Current consumption 0,30 A 0,60 A
Resistance of magnetic base 5% bei 25°C (627-693 Ohm) 660 Ohm 160 Ohm
Minimum drilling force min. 2700 N
Test voltage on motor without electronics 180 V / AC 86 V / AC
