KBM 52 U / KBM 50 Q
EN
Instruction manual for core drill.
Symbols, abbreviations and terms
used.
The symbols used in this Instruction Manual and
where necessary on the power tool, serve to
draw your attention to possible hazards when
working with this power tool.
It is mandatory for you to understand the sym-
bols/information and to act accordingly, in order
for the power tool to be implemented more
efficiently and more safely.
The safety warnings, information and symbols
do not serve as a substitute for the measures to
be taken according to the regulations for the
prevention of accidents.
Symbol Term, meaning Explanation
➤ Action Action to be taken by the user
General prohibition sign Follow the instructions in the adjacent text!
Touching prohibited Do not touch the rotating parts of the power tool.
Secure against falling Secure the power tool with the clamping strap if
there is danger of it falling.
General mandatory sign Follow the instructions in the adjacent text!
Read documentation Be absolutely sure to read the enclosed documen-
tation such as the Instruction Manual and the Gen-
eral Safety Instructions.
Open the folding page For a better understanding, unflap the folding page
at the beginning of this Instruction Manual.
Pull out mains plug Before commencing this working step, pull the
mains plug out of the socket. Otherwise there will
be danger of injury if the power tool should start
unintentionally.
Use eye-protection Use eye-protection during operation.
Wear ear protection Use ear protection during operation.
Use dust mask Use a dust mask during operation.
Use protective gloves Use protective gloves during operation.
Danger warning Observe the information in the adjacent text!
Hot surface warning An exposed surface is very hot if touched and
therefore dangerous.
European conformity symbol Confirms the conformity of the power tool with
the directives of the European Community.
