AA
Phillips
Screwdriver
CCBB DD
HARDWARE INCLUDED
TOOLS REQUIRED (NOT INCLUDED)
NOTE: Hardware not shown to actual size.
Pre-Assembly
IMPORTANT WIRING INFORMATION
Always follow the recommended wire strip lengths
and wiring combinations when connecting wires.
Hold stripped ends next to
each other and align frayed
strands (do not twist wires).
Push wires firmly into wire nut. Using your fingers,
twist wire nut clockwise until tight. Check for
tightness by pulling wires.
FF HHGG
EE
II
Part Description Quantity
AA Fixture Body 1
BB Crossbar 1
CC Fixture Mounting Thumb Screws 2
DD J-box Mounting Screws 2
EE Wire Nuts 3
FF Rubber Washers 2
GG Sensor Cover 1
HH ST19 LED Light Bulb 1
II Glass Shade 1
Sealant
Please contact feit.com/help for further assistance.
3
To Next Page
