FeiYu Tech VIMBLE 3 - Gimbal Components Overview

2
1. Overview
[10]
[11]
[12]
[13]
[1]
[8]
[6]
[5]
[7]
[3]
[2]
[4]
[24]
[25]
[26]
[27]
[14]
[15]
[9]
[16]
[17]
[18]
[20]
[19]
[22]
[21]
[23]
[1] Roll axis
[2] Cross arm
[3] Tilt axis
[4] Vertical arm
[5] Pan axis
[6] Upper trigger button
(Custom functions in APP)
[7] Lower trigger button
[8] Handle (Built-in battery)
[9] Type-C port for accessories
[10] Limitation
[11] A button
[12] B button
[13] Zoom button
[14] Smartphone holder
[15] Extendable rod
(Extendable range
0~198mm)
[16] Joystick
[17] Dial
[18] Dial function switching
button
[19] Status indicator
[20] Battery indicator
[21] Album button
[22] Mode button
[23] Shutter button
[24] USB-C port
[25] Power button
[26] 1/4 inch thread
hole
[27] Tripod
* This product dose NOT include smartphone.
