Spooler Manual 18
User Interface
> Diameter: 1.75
1.74 0.69
> Mode: Soft
1.74 0.69
> Travel: 80
1.74 0.69
> PullSpd: 1.18
1.74 0.69
> TravSpd: Auto
1.74 0.69
> SpoolSpd: 12
1.74 0.69
> FanSpd: 255
1.74 0.69
Listed below there are all the parameters (menu items) that you can modify every time
you need during the extruding session.
Filament diameter desired.
From 0.5mm to 3mm
Preset for auto measuring and calibration.
See page 12 for more information.
Puller wheels constant speed. Adjust this parameter
according to your extrusion flow.
Available only in “Manual Mode”
Travel distribution width, modify this parameter
according to your spool width.
Travel distribution Speed. By default is set on
“auto” mode. This parameter can affect the filament
distribution.
Spool Speed. Modify this parameter if the spool
clutch is not working properly for your material, or if
your extrusion flow is over 1,5m/m
Fan Speed. You can modify the airflow of fan array if
necessary.
