Fellowes AutoMax 100M Manual

2
CAPABILITIES
ENGLISH
Model 100M
Will shred: Paper, plastic credit cards*, staples* and small paper clips*
* Manual Feed
Will not shred: Adhesive labels, CD/DVDs, continuous form paper, transparencies,
newspaper, cardboard, large paper clips, laminates, file folders, X-rays or plastic other than
noted above
Paper shred size:
Mini-Cut .......................................................................................................4mm x 10mm
Maximum:
Sheets per pass (Auto Feed) ....................................................................................... 100*
Sheets per pass (Manual Feed) .................................................................................... 10*
Cards per pass ............................................................................................................... 1*
Paper entry width .................................................................................................. 220mm
* A4 (70g), paper at 220-240V, 50/60 Hz, 3.5Amps; heavier paper, humidity or other
than rated voltage may reduce capacity. Maximum recommended daily usage rates:
1000sheets; 15 credit cards.
IMPORTANT SAFETY INSTRUCTIONS — Read Before Using!
15
3
IMPORTANT SAFETY INSTRUCTIONS — Read Before Using!
15
KEY FEATURES AND CONTROLS
A. Auto Feed Tray
B. Auto Feed Flap
C. Disconnect Power Switch
1. OFF
2. ON
D. Manual Feed Slot
E. Pull-Out Bin
F. Casters
G. Auto Feed Tray Extension
H. See Safety Instructions
I. Control Panel and LEDs
1. Reverse
2. ON/OFF and Start (blue)/Bin Open
3. Remove Paper (red)
4. Bin Full (red)
5. Overheat (red)
*Apply oil across entry
Press and hold Reverse
( ) for 2-3 seconds
Overheat Indicator: When the Overheat Indicator is illuminated, the shredder has exceeded its maximum operating temperature and needs to cool down. This
indicator will remain illuminated and the shredder will not operate for the duration of the recovery time. See Basic Shredding Operation for more information about
the continuous operation and recovery time for this shredder.
Remove Paper: When illuminated, set to reverse ( ) and remove paper. Reduce paper quantity to an acceptable amount and refeed into paper entry.
TROUBLESHOOTING
PRODUCT MAINTENANCE
TO CLEAN THE SENSORS
CLEANING AUTO-START INFRARED SENSORS
Paper detection sensors are designed for maintenance free operation. However, on rare occasions the sensors
may become blocked by paper dust causing the motor to run even if there is no paper present.
(Note: the paper detection sensors is located in the center of the paper entry).
All mini-cut shredders require oil for peak performance. If not oiled, a
machine may experience diminished sheet capacity, intrusive noise when
shredding, and could ultimately stop running. To avoid these problems, we
recommend you oil your shredder each time you empty your waste bin.
OILING SHREDDER
15
15
* Only use a non-aerosol vegetable oil in long
nozzle container such as Fellowes 35250
FOLLOW OILING PROCEDURE BELOW AND REPEAT TWICE
Turn off and unplug
shredder
Locate Auto-start infrared sensor
ADVANCED PRODUCT FEATURES
For more information about all of Fellowes Advanced Product Features go to www.fellowes.com
WHEN IN SLEEP MODE
To get out of sleep mode,
press start ( )
Insert paperor
SilentShred™ Technology
SilentShred™ shreds without
noisy disruptions.
Energy Saving Sleep Mode
Feature shuts down the shredder
after 2 minutes of inactivity
Auto Reverse
Stops and reverses paper if
a jam occurs.
Continuous operation: up to
15 minutes maximum
NOTE: Shredder runs briefly
after each pass to clear
entry. Continuous operation
beyond 15 minutes will trigger
35-minute cool down period.
BASIC SHREDDING OPERATION
MANUAL FEED
AUTO FEED
Plug in and put
disconnect power
switch in ON (I) position
Plug in and put
disconnect power
switch in ON (I) position
Extend auto feed
paper tray*
Press start ( ) to
begin shredding
Add paper
1
1
* Do not use auto feed tray extension to move shredder.
Using cotton swab, wipe away any
contamination from the paper sensors
Dip cotton swab in
rubbing alcohol
Feed paper/card
straight into paper
entry and release
BASIC SET UP
CASTER INSTALLATION
1 2 3
1
7
A
UT
O
79Ci
1
79Ci
3
1 2 3
1
7
A
UT
O
79Ci
1 2 3
1
7
A
UT
O
79Ci
42
79Ci
C.
B.
A.
I.
H.
F.
D.
E.
G.
SLEEP MODE OPERATION
Feature shuts down the shredder after 2 minutes of inactivity
4
3
2
2
1
2
1
2
3
2
4
1
Bin Full: When illuminated, the shredder waste bin is full and needs to be emptied. Use Fellowes waste bag 36053.
Bin Open: The shredder will not run if the bin is open. Close the bin to resume shredding.
15
• Operation,maintenance,andservicerequirementsarecoveredinthe
instruction manual. Read the entire instruction manual before operating
shredders.
• Keepawayfromchildrenandpets.Keephandsawayfrompaperentry.
Always set to off or unplug when not in use.
• Keepforeignobjects–gloves,jewelry,clothing,hair,etc.–awayfrom
shredder openings. If object enters top opening, switch to Reverse ( )
to back out object.
• DO NOT use aerosol products, petroleum based or aerosol lubricants on or
near shredder. DO NOT USE “CANNED AIR” OR “AIR DUSTERS” ON SHREDDER.
Vapors from propellants and petroleum based lubricants may combust causing
serious injury.
• Donotuseifdamagedordefective.Donotdisassembleshredder.Donot
place near or over heat source or water.
• Movingparts:donottouch.
• ThisshredderhasaDisconnectPowerSwitch(C)thatmustbeintheON(I)
position to operate shredder. In case of emergency, move switch to OFF ( )
position. This action will stop shredder immediately.
• Avoidtouchingexposedcuttingbladesundershredderhead.
• Shreddermustbepluggedintoaproperlygroundedwalloutletorsocketof
the voltage and amperage designated on the label. The grounded outlet or
socket must be installed near the equipment and easily accessible. Energy
converters, transformers, or extension cords should not be used with this product.
• FIREHAZARD–DoNOTshredgreetingcardswithsoundchipsorbatteries.
• Forindooruseonly.
• Unplugshredderbeforecleaningorservicing.
15
15
15
Automax_100M_410863_RevB_24L_102918.indd 2-3 10/29/18 11:27 AM

Fellowes AutoMax 100M Specifications

General

Reverse	Yes
Basket volume	23 L
Product color	Black
Shredding CDs	-
Working width	220 mm
Shredding size	4 x 10 mm
Shredding type	Micro-cut shredding
Security level (paper)	P-4
ISO A-series sizes (A0...A9)	A4

Weight and Dimensions

Depth	370 mm
Width	390 mm
Height	640 mm
Weight	13600 g
