-36-
1 4
2
5
3 6 7
4. Rear Dropout Grommet
5. Top Tube Double Hole Grommet
6. Bottom Bracket Grommet
7. *Junction B
AR Cable Routing & Small Parts
1. *Shimano Di2 Wires
2. Downtube Gromemt (x2)
3. *Shimano 8mm Front Derailleur Grommet
*not included with AR frame
AR Mechanical Compatible Frame
Electronic Wiring Instructions
