ACOUSTASONIC PRO
PARTS LIST
NOTE: SHADED ITEMS ARE FOR REFERENCE ONLY
PRINTED CIRCUIT BOARD ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
3 048451000 BUTTON PUSH OFF WHITE at S502-504
3 040987000 CABLE RIBBON 10CKT 3.75" PW3-5
1 037943003 CAP AE RDL .33uF 50V 20% C310
1 028492000 CAP AE RDL 1000uF 16V 20% C314
2 028494000 CAP AE RDL 1000uF 35V 20% C321-322
3 031040000 CAP AE RDL 100uF 100V 20% C318-319 C326
1 028476003 CAP AE RDL 100uF 50V 20% C454
11 028459003 CAP AE RDL 2.2uF 50V 20% C102 C202 C320 C405-406C410 C423 C425
C506 C523 C527
2 028482003 CAP AE RDL 220uF 50V 20% C316-317
21 028467003 CAP AE RDL 22uF 50V 20% C101 C108-109 C201 C208-209 C301-306
C421-422 C504 C518-519 C525-526 C529-
530
2 028460003 CAP AE RDL 4.7uF 50V 20% C435 C531
3 028485003 CAP AE RDL 470uF 16V 20% C315 C457 C548
6 028471003 CAP AE RDL 47uF 50V 20% C115-116 C215-216 C323-324
3 047195003 CAP AE RDL 47uF 63V 20% C311 C403-404
2 037182000 CAP AE RDL 6800uF 63V 20% C312-313
8 051405003 CAP CD 120pF 500V 5% C401-402 C407-408 C431-432 C524 C528
2 051445003 CAP CD 22pF 500V 5% C411 C505
2 051413003 CAP CD 33pF 500V 5% C424 C426
2 051458003 CAP CD 470pF 500V 10% C427-428
2 051459003 CAP CD 560pF 500V 10% C414 C509
5 051409003 CAP CD 68pF 500V 5% C111-112 C211-212 C515
51 034788003 CAP CR .1uF 50V 20% .15" cut C113-114 C122-123 C213-214 C222-223
C325 C327-330 C436-453 C456 C458 C514
C532-547 C549
3 027257003 CAP MPF .0022uF 100V 10% C511-513
2 027261003 CAP MPF .0047uF 100V 10% C103 C203
2 027262003 CAP MPF .0068uF 100V 10% C413 C508
6 027264003 CAP MPF .01uF 100V 10% C106-107 C206-207 C417-418
1 047165000 CAP MPF .01uF 250V 20% C307
4 027267003 CAP MPF .022uF 100V 10% C415-416 C502 C516
6 027269003 CAP MPF .033uF 63V 10% C104-105 C204-205 C429-430
2 027280003 CAP MPF .15uF 63V 10% C433-434
8 052003003 CAP MPF .1uF 250V 10% C119-121 C219-221 C308-309
3 027281003 CAP MPF .22uF 63V 10% C455 C510 C520
4 027285003 CAP MPF .39uF 63V 10% C409 C412 C507 C517
1 027286003 CAP MPF .47uF 63V 10% C503
2 033477003 CAP MPF.68uF 63V 10% C419 C521
ACOUSTASONIC PRO
PARTS LIST
PRINTED CIRCUIT BOARD ASSEMBLY (CONT.)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
4 033580003 CAP PFF RDL .0022uF 100V 10% C117-118 C217-218
4 031089000 CONTROL 100K 10C
R424 R438 R453 R545 Fdbk1, Fdbk2, Aux
Gain, Master
1 027949000 CONTROL SNAPIN 250K 30C TAPER
R531 Srting Dynamics
7 027942000 CONTROL SNAPIN 50K 2B CTR DET
R413-415 R510-512 R516 Bass, Mid, Treble,
Attack
4 027943000 CONTROL SNAPIN 50K 30C TAPER
R410 R479 R506 R560 Inst gain & FX rtrn;
MIC gain & FX rtrn
2 027941000 CONTROL SNAPIN 50K B TAPER
R446 R540 Inst DSP Send, Mic DSP Send
1 051931000 DIN CONNECTOR, 5-PIN FEMALE J304
21 064089001 DIODE 1N4003 LL D118-119 D218-219 D308-310 D316-317
D328-331 D312-315 D318-321
34 006260001 DIODE 1N4448 SIGNAL LL
D101-107 D112-115 D120-121 D201-207 D212-215
D220-221 D301 D324-327 D501-503
4 029045000 DIODE 6A 400V 6A4 LEAD FORMED D304-307
4 025821001 DIODE HV FDH-400 SWITCHING LL D108-109 D208-209
4 054210001 DIODE SCHOTTKEY BAT85 D110-111 D210-211
3 031017001 DIODE ZEN 1N5223B 2.7v 5% LL D323 D504-505
5 031729001 DIODE ZEN 1N5231B.5w 5.1v 5% D116-117 D216-217 D311
2 031635001 DIODE ZEN 1N5240B 10V 5% LL D302-303
1 028119060 DIODE ZEN 1N5353B 16V 5W 5% D322
14 025802000 FSTN TAB MALE .250X.032 PCB MT CP101-104 CP201-202 CP301-302 CP305-
307 CP309-310 CP312
2 026000001 FSTN TAB MALE PCB MT .187X.032 CP308 CP311
6 051094003 FUSE CLIP, PCB 5MM (EXPT) at F301-303
5 027419000 HDR .1 CTR 10 CKT SQ PIN P1-5
6 050849000 HEATSINK PCB LEVEL at Q111-112 Q211-212 U303-304
1 053575000 HEATSINK PLATE 160W AMPS HS21
1 027404000 IC CA3080AE OTA U504
2 016795000 IC DUAL OP AMP TL072 U501 U505
18 031611000 IC DUAL OP AMP PC4560
U101 U201 U301-302 U401-409 U502-503 U506-
508
1 013562000 IC REGULATOR +15V MC7815CT U303
1 013564000 IC REGULATOR -15V MC7915CT U304
4 038815000 INSULATOR SILICONE TO-3P at U113-114 U213-214
7 051658000 JACK MONO R/A J101-102 J201-202 J301-303
1 025933000 JACK PHONO DUAL PC MTG J403
2 053450000 JACK STEREO R/A J402 J501
1 049948000 LED, RED LONG LEAD LUMEX D400
