ACOUSTASONIC PRO
PARTS LIST
PRINTED CIRCUIT BOARD ASSEMBLY (CONT.)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
6 097360000 NUT, HEX 4-40 EX LOCK at Q111-112 Q211-212 U303-304
1 051903000 PCB FAB ACOUSTASONIC PRO
1 031767001 RES CF 1/2W 15 ohm 5% R323
4 024997001 RES CF 1/4W 100k 5% R314 R322 R447 R541
15 024981001 RES CF 1/4W 10k 5% R324 R419-421 R427-428 R430 R433-435
R441-442 R444 R456 R458
9 024937001 RES CF 1/4W 10ohm 5%
R131-132 R231-232 R432 R482-483 R551 R559
3 024985001 RES CF 1/4W 15k 5% R106 R206 R328
4 024986001 RES CF 1/4W 18k 5% R425-426 R439-440
18 024965001 RES CF 1/4W 1k 5% R111-113 R115-116 R152 R211-213 R215-
216 R252 R318-320 R325 R522 R530
2 025069001 RES CF 1/4W 1M 5% R429 R443
16 024971001 RES CF 1/4W 2.2k 5%
R105 R109 R125 R128 R205 R209 R225 R228
R315 R412 R416 R423 R437 R504 R509 R513
4 029455001 RES CF 1/4W 2.4k 5% R126-127 R226-227
4 025059001 RES CF 1/4W 220k 5% R418 R505 R515 R529
16 024987001 RES CF 1/4W 22k 5%
R464-467 R471-474 R476 R478 R532-535 R552-
553
6 024988001 RES CF 1/4W 27k 5% R114 R120 R153 R214 R220 R253
1 029610001 RES CF 1/4W 3k 5% R317
2 028865001 RES CF 1/4W 30k 5% R417 R514
6 024989001 RES CF 1/4W 33k 5% R110 R210 R431 R445 R451-452
10 024977001 RES CF 1/4W 4.7k 5%
R119 R219 R409 R507 R536-537 R547-548 R555-
556
1 025828001 RES CF 1/4W 430k 5% R524
10 025065001 RES CF 1/4W 470k 5% R411 R449 R508 R538-539 R543 R549-550
R557-558
10 024993001 RES CF 1/4W 47k 5% R102-103 R202-203 R316 R327 R329 R517-
519
20 024952001 RES CF 1/4W 5% 100 ohm LL R101 R201 R302 R304-307 R309 R311-312
R457 R460-462 R468-470 R475 R477 R523
1 025084001 RES CF 1/4W 5% 10M LL R502
4 024983001 RES CF 1/4W 5% 12k LL R107-108 R207-208
2 024954001 RES CF 1/4W 5% 150 ohm LL R480 R561
2 024955001 RES CF 1/4W 5% 180 ohm LL R450 R544
4 024972001 RES CF 1/4W 5% 2.7k LL R137 R139 R237 R239
3 029006001 RES CF 1/4W 5% 20k LL R313 R459 R463
4 024942001 RES CF 1/4W 5% 22 ohm LL R117-118 R217-218
1 025079001 RES CF 1/4W 5% 4.7M LL R527
2 026510001 RES CF 1/4W 5% 9.1k LL R422 R436
1 028948001 RES CF 1/4W 6.2k 5% R326
6 024979001 RES CF 1/4W 6.8k 5% R104 R204 R301 R303 R308 R310
4 024995001 RES CF 1/4W 68k 5% R454-455 R546 R554
1 025942001 RES CF 1/4W 7.5k 5% R503
ACOUSTASONIC PRO
PARTS LIST
PRINTED CIRCUIT BOARD ASSEMBLY (CONT.)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 027627001 RES FILM 1W 10ohm 5% R321
4 037354001 RES FILM 1W 4.7k 5% LL R129 R134 R229 R234
4 054368001 RES FP 1/2W 1.5k 5% R130 R133 R230 R233
2 015581001 RES MF 1/4 W 9.53k LL 1% R448 R542
2 031819001 RES MF 1/4W 1% 1.82k LL R403-404
1 015582001 RES MF 1/4W 1% 10k LL R520
4 031818001 RES MF 1/4W 1% 18.2k LL R405-408
1 025816001 RES MF 1/4W 1% 20k LL R521
2 016961001 RES MF 1/4W 1% 6.81k LL R401-402
2 016953001 RES MF 1/4W 1.78k LL 1% R481 R562
4 027750001 RES MF FUSE 1/4W 5% 100ohm R123-124 R223-224
8 051731001 RES MF FUSE 1/4W 5% 1k ohm R121-122 R138 R140 R221-222 R238 R240
6 036960001 RES MF FUSE 1/4W 5% 47 OHM LL R135-136 R144 R235-236 R244
4 031628001 RES MOF 2W 5% .22ohm LONG LEAD R146-147 R246-247
2 051417001 RES MOX 2 W 22 OHM LL 5% R149 R249
1 034704001 RES MOX 2W 180ohm 5% LL R400
2 041500000 RES WW BT 5W 10% 4.7 ohm R331
1 037845000 RES WW BT 5W 10% 47 ohm R151
6 039420000 SCRW M 4-40X3/8 PHP SS SEMS at Q111-112 Q211-212 U303-304
2 037985000 SCRW SMA 2x3/8 PHP BLX At J304
4 027638000 SCRW TF 4-40x3/8 HWHS ZI .1"HD At Q113-114 Q213-214
5 032908000 SCRW TF 6-32X3/8 PHP ZI At HS21
1 036178000 SPACER LED .5x.1 BRN At D400
3 028091000 SWITCH PUSH SLFLK SHRT STROKE S502-504
1 051418003 THERMAL SENSOR PTC 100DEG C RT301
1 051019000 XLR CONNECTOR FEMALE RT ANGLE J401
1 049892000 XLR JACK MALE J305
