ACOUSTASONIC PRO
PARTS LIST
PRINTED CIRCUIT BOARD ASSEMBLY (CONT.)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 014689003 XSTR N-CH JFET J111 TO-92 Q308
2 016739003 XSTR NPN 2N4401 TO-92 Q109 Q209
7 025751003 XSTR NPN 2SC2362K/2SC2389STPS Q101-103 Q201-203 Q303
2 028760000 XSTR NPN 2SC3298A TOP-220 Q111 Q211
3 051448003 XSTR NPN 2SD1857 Q107 Q207 Q304
2 051725000 XSTR NPN MJW21192 TO 247 Q113 Q213
3 014867003 XSTR NPN MPSW42 (TO-92) Q106 Q206 Q307
3 016742003 XSTR PNP 2N4403 TO-92 Q110 Q210 Q301
3 025752003 XSTR PNP 2SA1038STPS Q104 Q204 Q302
3 028759000 XSTR PNP 2SA1306A TOP-220 Q112 Q212 Q306
3 051447003 XSTR PNP 2SB1236 Q108 Q208 Q305
2 051724000 XSTR PNP MJW21191 TO 247 Q114 Q214
2 014866003 XSTR PNP MPSW92 TO-226AE Q105 Q205
CHASSIS ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 050833000 CHASSIS ACOUSTASONIC PRO
1 020795000 FUSE QA 20mmx5mm 250v 2.5A
230V/240V ONLY
1 053885000 FUSE QA 20mmx5mm 250v 5A
100V/120V ONLY
2 013112000 FUSE TD 20mmx5mm 250V 1A
ALL VARIATIONS
1 048974000 HEATSINK EXTRUDED BXR 200
1 054798000 JEWEL ASSY., LED
1 051752000 KNOB BROWN/BLANK
18 051017000 KNOB ROTARY BRN/WHT
1 051895000 PANEL FRONT ACOUSTASONIC PRO
1 051896000 PANEL REAR ACOUSTASONIC PRO
1 051899000 PCB ASSY ACOUSTASONIC PRO
1 051900000 PCB ASSY ACOUSTASONIC PRO DSP
ACOUSTASONIC PRO
PARTS LIST
CHASSIS ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 028069000 BUSHING SNAP 3/4x1-1/8 WHT CABLES
5 069393000 NUT 6-32 HEX EXT LOCK DSP/GND
1 031625000 NUT HOLDER PILOT LIGHT 1/16-27
6 017716000 SCRW 8-32x1/2 PHP BLX @ HS/CHASSIS
1 017433000 SCRW M 6-32x3/8 PHP BLX GND
6 031184000 SCRW M6-32x1/4 PHPS BLX ITLW @ STANDOFFS
5 051155000 SCRW SMB #4X3/8 PHP BLX @ XLR & RCA
4 037997000 SCRW TF 10-32x5/8 HWHS BLX @ XFMR
5 027636000 SCRW TF 8-32x5/8 HWH BLX @ HS/PLATE
1 054642000 SOCKET, IEC SNAP IN
4 051905000 SPACER RND NYL .120X.187X.315 @ DSP
4 025936000 STANDOFF NYL PCB SNAP 3/8" NAT @ DSP SNDWCH
2 051404000 STANDOFF, NYLON BLACK @ BTM PCB
3 016440000 STNDOFF RND AL 6-32x1x1/4 @ PWR AMP
1 031153000 WSHR FLAT 3/8x.614 NI ENCODER/CHS
1 040582000 SWITCH DPST .250 TAB GLOBAL
POWER 230V/240V ONLY
1 039236000 SWITCH ROCKER DPST PSEUDO-IEC
POWER 100V/120V ONLY
1 053886000 XFMR PWR DOMESTIC 120V 160W
120V DOMESTIC ONLY
1 053888000 XFMR PWR EXPORT 230V 160W
230V-240V EXPORT ONLY
1 053887000 XFMR PWR JAPAN 100V 160W
100V JAPAN ONLY
CABINET ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
0.4 036797000 CLOTH GRILLE TAN/BRN
1.6 036796000 TOLEX BROWN COVERING
0.2 029086000 VELCRO STRIP HOOK 1.5"wd BLK
0.2 029085000 VELCRO STRIP LOOP 1.5"wd BLK
2 026566000 CORNER 2 HOLE w/TAB NI
2 029071000 CORNER NOTCHED NICKEL (FD)
4 019276000 GLIDE CAB 1.24x.335 NI
4 019275000 INSERT GLIDE CUSHION 1.27 DIA.
2 025395000 HANDLE CAP 1 HOLE NI(DWG17240)
1 037121000 HANDLE STRAP BRN
1 032524000 INSERT HANDLE
10 021972000 NUT T 10-32x3/4 STR 3 PRNG BLX
2 022244000 SCRW M 10-32X1-1/8 OHP NI
4 037543000 SCRW SMAB 8x3/4 OHP NI
4 026625000 SCRW WOOD 8x1 FH
To Next Page
