ACOUSTASONIC PRO
PARTS LIST
END ITEM ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 050832000 CAB ASSY ACOUSTASONIC PRO
1 051876000 CHASSIS ASSY AC PRO 100V 100V JPN
1 051872000 CHASSIS ASSY AC PRO 120V 120V DOM
1 051875000 CHASSIS ASSY AC PRO 230V 230V EUR
1 051873000 CHASSIS ASSY AC PRO 230V U.K. 230V U.K.
1 051874000 CHASSIS ASSY AC PRO 240V AUST 240V AUST
1 053997000 CORD PWR W/IEC CONN 100V JPN 100V JPN
1 047251000 CORD PWR W/IEC CONN 230V 230V EUR
1 047249000 CORD PWR W/IEC CONN 230V UK 230V U.K
1 047250000 CORD PWR W/IEC CONN 250V 240V AUST
1 047248000 CORD PWR W/IEC CONN DOM 120V DOM
1 051900008 DSP ASSEMBLY
1 054819000 EFFECTS LIST, ACOUSTASONIC PRO
1 051894000 FOOTSWITCH ASSY. 4 BUTTON DSP (SCHEMATIC IS PART OF SERVICE
DIAGRAM)
1 049260000 HORN CERAMIC PIEZO KXR 60
2 051016000 SPEAKER 8" 8 OHM Hi-Fi
2 051904000 LEG AMP TILTBACK 15" LEGS
1 051870000 LOGO PLATE, ACOUSTASONIC PRO
1 036795000 NAMEPLATE 62 FENDER LOGO
2 021998000 NUT FLEX LOCK W/NYLON IN @ LEGS
A/R 036650000 PIN ESCUTCHEON #18x3/8 NI @ NAMEPLATE
4 9904101110 SCREW PB 8x5/8 PHP BLX @ HORN
6 053483000 SCRW 8-32x1-3/8#6 OHP w/WSHR NI CHS MNT
8 026577000 SCRW M 10-32X1 PHP BLX @ SPEAKERS
2 022277000 SCRW M 10-32X1-1/2 OHP NI @ LEGS
2 031344000 SCRW SMA 10X3/4 OHP NI @ LEGS
4 037210000 SCRW SMA 2x3/8 OHP NI @ LOGO
2 024646000 WASHER LEG STOP TN @ LEGS
6 022319000 WSHR FLAT 1/4x9/16 NI @ LEGS
2 022285000 WSHR SP LOCK 1/4x.493 ZI @ LEGS
ACOUSTASONIC PRO
PARTS LIST
FOOTSWITCH ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 051928000 CABLE, 5-PIN DIN
1 033263000 HOUSING FTSW 4 BUTTON
1 028109000 HSG END CAP LEFT FTSW
1 051927000 HSG END CAP RIGHT FTSW
1 051926000 PLATE TOP 4 BUTTON DSP FTSW
1 054773000 PCB ASSY FTSW 4 BTN DSP
1 051931000 CONNECTOR, DIN, 5-PIN FEMALE PART OF PCB ASSY
1 051929000 PCB FAB FOOTSWITCH DSP PART OF PCB ASSY
4 051930000 SWITCH PUSH PCB MTG. TYPE PART OF PCB ASSY
2 051155000 SCRW SMB #4X3/8 PHP BLX @ MIDI JACK
8 028684000 SCRW SMB 6x3/8 PH PHS BLX @ END CAPS
4 031899000 WSHR NYL .485x.775x.150 TK
DSP ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 040987000 CABLE RIBBON 10 CKT 3.75"
1 054303000 CABLE RIBBON 10 CKT 7.5"
1 038692001 CAP AE AX 10uF 35V 20%
4 028463003 CAP AE RDL 10uF 50V 20%
2 028458003 CAP AE RDL 1uF 50V 20%
2 028460003 CAP AE RDL 4.7uF 50V 20%
6 051445003 CAP CD 22pF 500V 5%
4 051413003 CAP CD 33pF 500V 5%
31 034788003 CAP CR .1uF 50V 20% .2" LS
2 027260003 CAP MPF .0039uF 100V 10%
2 027283003 CAP MPF .33uF 63V 10%
2 030931003 CAP PFF RDL .001uF 50V 5%
1 030946003 CAP PFF RDL .012uF 50V 5%
1 051197000 CRYSTAL, 16.384MHz, 18pF
1 051195000 CRYSTAL, 4.000 MHz, 18 pF
7 006260001 DIODE 1N4448 SIGNAL LL
1 051924000 ENCODER, 2 BIT, 36 DETENT
1 041812000 IC REGULATOR +5V 1.5A
1 054380003 IC REGULATOR +5V 100mA
1 053540000 IC, CODEC, AK4520A
1 051050000 IC, DSP, 56004
1 051189000 IC, EEPROM, SERIAL, 128x8
1 055347000 IC, EPROM, 64Kx8
