ACOUSTASONIC PRO
PARTS LIST
DSP ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 055348000 IC, MICROCNTRLLR, 68HC705
2 511910000 IC, OCTAL LATCH
1 511900000 IC, QUAD NAND GATE
1 051193003 IC, RESET CNTRLLR, +5V
1 051188000 IC, SRAM, 128Kx8
1 053951003 LED RED T-1.75 CLR
1 051925000 LED, 7 SEG, CMN ANODE, RED
1 049948003 LED, RED LONG LEAD LUMEX
1 054768000 PCB FAB, AC PRO DSP ASSY
5 024952001 RES CF 1/4W 5% 100ohm LL
12 024981001 RES CF 1/4W 5% 10k LL
1 024937001 RES CF 1/4W 5% 10ohm LL
2 024955001 RES CF 1/4W 5% 180ohm LL
1 024965001 RES CF 1/4W 5% 1k LL
2 025069001 RES CF 1/4W 5% 1M LL
10 024956001 RES CF 1/4W 5% 220ohm LL
5 029005001 RES CF 1/4W 5% 2k LL
4 024973001 RES CF 1/4W 5% 3.3k LL
2 029451001 RES CF 1/4W 5% 430ohm LL
2 024993001 RES CF 1/4W 5% 47k LL
5 024962001 RES CF 1/4W 5% 560ohm LL
1 097360000 NUT HEX 4-40 EX LOCK
1 039420000 SCRW M 4-40X3/8
2 051145000 SOCKET, IC, DIP, 28 PIN
1 054657000 SPACER LED .2X.1 ORANGE
4 025936000 STANDOFF NYL PCB SNAP
4 051194000 SWITCH, SPST N/O, MOM
4 016739003 XSTR NPN 2N4401 TO-92
