BASSMAN 25

PARTS LIST

CHASSIS ASSEMBLY

QTY PART # DESCRIPTION REFERENCE DESIGNATION

1 0055660000 CHASSIS BASSMAN 25

1 0054642000 CONNECTOR IEC SNAP IN

1 0020786000 FUSE QA 20mmx5mm 250v .500A 230V/240V

1 0048381000 FUSE QA 20mmX5mm 250V 1A CSA 100V/120V

1 0034885000 HEATSINK BAR RD/HT/JM/CHMP110

5 0055776000 KNOB ROT W/ CH INS BASSMAN

5 0033206000 BUSHING KNOB SPACER

1 0055661000 PANEL FRONT BASSMAN 25

1 0055662000 PANEL REAR BASSMAN 25

1 0055620000 PCB ASSY DOM BASSMAN 25

1 0055657000 PCB ASSY EXP BASSMAN 25

4 0069393000 NUT 6-32 HEX EXT LOCK @ Xfmr

8 0055838000 NUT PLASTIC REAN @ Jacks

1 0051155000 SCRW SMB #4X3/8 PHP BLX @ RCA Jack Assy

1 0038900000 SCRW TF 6-32X1/4 PHP ZI @ Chassis Ground

2 0028500000 SCRW TF 8-32x3/4 HWH SLTD Z1 @ H.S. Bar

3 0051404000 STANDOFF NYLON BLK .375

1 0025935000 SWITCH DPST .187 TAB (DOM) Domestic & Export

1 0033613000 XFMR PWR 120v

1 0040611000 XFMR PWR CHMP110/BXR25 230V

CABINET ASSEMBLY

QTY PART # DESCRIPTION REFERENCE DESIGNATION

0.1 0040046000 CARPET BLACK

2 0029071000 CORNER NOTCHED NICKLE (FD)

8 0019276000 GLIDE CAB 1.24x.335 NI

8 0019275000 INSERT GLIDE CUSHION 1.27 DIA

1 0027846000 HANDLE 9.25" NO LOGO

2 0025395000 HANDLE CAP 1 HOLE NI(DWG17420)

1 0032524000 INSERT HANDLE

6 0021972000 NUT T 10-32X3/4 STR 3 PRNG BLX

2 0022244000 SCRW M 10-32x1-1/8 OHP NI

4 0026571000 SCRW SMAB 8X5/8 THP NI

6 0026625000 SCRW WOOD 8x1 FH

0.01 0040149000 TAPE ALUM 5"X60YDS

2 0053990000 TUBE CARDBD 2 1/8 ID X 1 5/8 L

1.26 0051343000 VINYL TOLEX 4227A
