SUPPLEMENT TO:
BLUES JUNIOR
PARTS LIST
NOTE: SHADED ITEMS ARE FOR REFERENCE ONLY
PRINTED CIRCUIT BOARD ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
3 0029533000 CABLE JMPR 22GA 4 CKT 3.2" PW2 PW4 PW5
2 0050687000 CABLE JMPR 6 CKT .156 ROUND PW1 PW3
1 0028577000 CABLE REVERB 30" @ WJ1-4
1 0038689001 CAP AE AX .47uF 100V 20% C20
2 0009512001 CAP AE AX 22uF 25V 20% C4 C18
3 0051720000 CAP AE AX 22uF 450V 20% C26-28
1 0038693001 CAP AE AX 47uF 16V 20% C1
1 0051719000 CAP AE AX 47uF 450V 20% C25
1 0028474003 CAP AE RDL 100uF 25V 20% C33
2 0028479003 CAP AE RDL 220uF 25V 20% C31 C34
2 0028489000 CAP AE RDL 470uF 50V 20% C30 C32
1 0038698001 CAP CA 47pF 100V C21
1 0039265001 CAP CA 2200pF 100V C19
1 0051457003 CAP CD 100pF 500V 5% C3
1 0051458003 CAP CD 470pF 500V 10% C17
1 0020909000 CAP CD 47pF 1000V 10% C14
1 0020917000 CAP CD 250pF 1000V 10% C5
1 0017620000 CAP CD 1500PF 1000V 10% C9
2 0024823000 CAP MPF RDL .01uF 400V 10% C11 C29
4 0024833000 CAP MPF RDL .022uF 400V 10% C6-7 C15-16
1 0024839000 CAP MPF RDL .033uF 400V 10% C10
2 0024853000 CAP MPF RDL .1uF 250V 10% C12-13
1 0024855000 CAP MPF RDL .1uF 630V 10% C24
2 0026202002 CAP PFF .0022uF 400V 10% C2 C8
1 0033581003 CAP PFF RDL .0033uF 100V 10% C23
1 0033588003 CAP PFF RDL .01uF 100V 10% C35
1 0036234003 CAP PFF RDL .015uF 100V 10% C22
1 0049402000 CONTROL SNAPIN 25k B R14
Middle
2 0034719000 CONTROL SNAPIN 50k B R19 R45
Master, Reverb
1 0041913000 CONTROL SNAPIN 250k 10A R13
Bass
1 0040985000 CONTROL SNAPIN 250k B R12
Treble
1 0049401000 CONTROL SNAPIN 1M 10A R5
Volume
2 0064089001 DIODE 1N4003 D5-6
4 0026730001 DIODE 1N4006 800V 1A D1-4
3 0006260001 DIODE 1N4448 SIGNAL D9 D13-14
2 0029690001 DIODE HV 3kV 200mA D11-12
2 0009165001 DIODE ZEN 1N4744A 15V 1W 5% D7-8
16 0025802000 FSTN TAB MALE .250x.032 PCB MT P1-16
2 0031041000 FSTN TAB ML RTANG PCB .25x.032 P17-18
2 0025996000 FUSE CLIP PCB 1/4" & 5mm DUAL F1
1 0031611000 IC OP-AMP DUAL PC4560 U1
1 0030771000 JACK 1/4 PCB 2/CD SCC J3
Speaker
1 0027674000 JACK 1/4 PCB 2/CD SCC INSL J2
Footswitch
1 0037036000 JACK PHONE PCB MONO PREM J1
Input
