SUPPLEMENT TO:
BLUES JUNIOR
PRINTED CIRCUIT BOARD ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 0056975000 LED RED PNL MT 7" D10
1 0024947001 RES CF 1/4W 5% 47ohm LL R39
1 0024964001 RES CF 1/4W 5% 820ohm LL R24
5 0024969001 RES CF 1/4W 5% 1.5k LL R4 R10 R17 R33-34
1 0029005001 RES CF 1/4W 5% 2k LL R43
2 0024977001 RES CF 1/4W 5% 4.7k LL R26 R40
1 0025942001 RES CF 1/4W 5% 7.5k LL R25
1 0026510001 RES CF 1/4W 5% 9.1k LL R29
4 0024981001 RES CF 1/4W 5% 10k LL R2 R7 R15 R42
3 0024987001 RES CF 1/4W 5% 22k LL R52 R57-58
2 0024989001 RES CF 1/4W 5% 33k LL R21 R51
1 0024995001 RES CF 1/4W 5% 68k LL R38
1 0028153001 RES CF 1/4W 5% 75k LL R27
3 0024997001 RES CF 1/4W 5% 100k LL R9 R11 R46
1 0028955001 RES CF 1/4W 5% 130k LL R6
5 0025059001 RES CF 1/4W 5% 220k LL R20 R31-32 R41 R44
1 0025828001 RES CF 1/4W 5% 430k LL R18
5 0025069001 RES CF 1/4W 5% 1M LL R1 R22-23 R37 R59
1 0025829001 RES CF 1/2W 5% 150ohm LL R56
1 0031065001 RES CF 1/2W 5% 91k LL R28
4 0025116001 RES CF 1/2W 5% 100k LL R3 R8 R16 R30
2 0041741001 RES MOX FP 1/2W 5% 47ohm LL R54-55
2 0028580001 RES MOX FP 1/2W 5% 100ohm LL R35-36
2 0031067001 RES FILM 1W 5% 750ohm LL R50 R53
2 0027349001 RES FILM 1W 5% 10k LL R48-49
1 0041258001 RES MOX 2W 5% 2.2k LL R47
1 0028091000 SWITCH PUSH SLFLK S1
1 0028104000 BUTTON PUSH SWITCH BLACK AT S1
5 0029167000 TUBE SOCKET 9 PIN PCB MOUNT V1-5
REF 0038519000 STANDOFF M/F 4-40 x 1/4L
REF 0097360000 NUT HEX 4-40 EX LOCK
REF 0047040000 STANDOFF NYL PCB SNAP 1/2" BLK
1 0014689003 XSTR N-CH JFET J111 TO-92 Q1
1 0057276000 PCB FAB BLUES JUNIOR
REF 0057275000 SERVICE DIAGRAM
To Next Page
