Fender Deluxe 112 User Manual

DELUXE 112
FOOTSWITCH ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
8 028889 SCREW SMB 6X1/4 PHP
2 034921 SPACER RND NYL .147X.250X.780
2 028714 SWITCH PUSH SPDT S1,2
2 031899 WASHER NYL .485X.775X.150 TK (SWITCH SPACER
MISCELLANEOUS
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 039358 MANUAL OWNERS “DELUXE 112”
1 039347 SCHEMATIC/SERVICE DIA. “DELUXE 112” (REDUCED TO 11X17

Fender Deluxe 112 Specifications

General

Speaker	12-inch Fender Special Design
Channels	2 (Clean and Drive)
Reverb	Yes
Type	Solid State
Inputs	2 x 1/4"
Outputs	1 x 1/4"
Controls	Gain, Volume, Treble, Bass, Mid, Reverb, Drive Select
Footswitch	Yes (Channel Switching and Reverb On/Off)
