DELUXE 90
SPECIFICATIONS
Product Release No.: PR 402 (This is not a model number)
Part Number: 120V Version : 22-6702-020
240V Aus : 22-6732-020
230V UK : 22-6742-020
230V Eur : 22-6762-020
100V : 22-6772-020
Power Requirements: 100V Version : 100 VAC 50/60 Hz, 360W
120V : 120 VAC 60 Hz, 360W
230V : 230 VAC 50 Hz, 360W
240V : 240 VAC 50 Hz, 360W
Power Amp Section
Power Output: 90 Watts into 4Ω @ 5% THD
Preamp Section
Input impedance: 850kΩ (Input 1) 66kΩ (Input 2)
Fuse: 4A 125V for 100V / 120V ver.
2A 250V for 230V / 240V ver.
Speaker Complement: One 4Ω Celestion G12T-100 12" Speaker (P/N 054421)
Footswitch: 2 Button Footswitch, for Chan. Select & Drive/More Drive (p/n
050419)
Dimensions: Height: 16.5" (42 cm)
Width: 20.6" (52.3 cm)
Depth: 9" (30.5 cm)
Weight: 33 lbs. (15 kg)
Product specifications are subject to change without notice
DELUXE 90
PARTS LIST
NOTE: SHADED ITEMS ARE FOR REFERENCE ONLY
PRINTED CIRCUIT BOARD ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
2 0038689001 CAP AE AX .47uF 100V 20% C17, C40
1 0038690001 CAP AE AX 1uF 100V 20% C15
4 0026517001 CAP AE AX 2.2uF 50V 20% C18, C34, C44, C47
2 0038692001 CAP AE AX 10uF 35V 20% C45, C59
6 0009512001 CAP AE AX 22uF 25V 20% C10-11, C32, C39, C61-62
2 0028463003 CAP AE RDL 10uF 50V 20% C57, C60
2 0028471003 CAP AE RDL 47uF 50V 20% C55-56
2 0028476003 CAP AE RDL 100uF 50V 20% C75-76
2 0031756000 CAP AE RDL 4700uF 50V C71-72
2 0038703001 CAP CA .1uF 50V C73-74
2 0039263001 CAP CA 1000pF 50V LL C4, C27
3 0038699001 CAP CA 100pF 100V LL C9, C31, C36
1 0039255001 CAP CA 10pF 100V LL C42
2 0039259001 CAP CA 220pF 100V LL C24, C43
1 0038700001 CAP CA 390pF 50V C38
2 0038701001 CAP CA 470pF 50V LL C16, C21
3 0051406003 CAP CD 220pF 500V 10% C41, C51-52
11 0034788003 CAP CR .1uF 50V 20% .2" LS C1, C78-87
1 0027255003 CAP MPF .001uF 100V 10% C8
1 0027257003 CAP MPF .0022uF 100V 10% C33
2 0027259003 CAP MPF .0033uF 100V 10% C29-30
2 0027261003 CAP MPF .0047uF 100V 10% C2-3
4 0027264003 CAP MPF .01uF 100V 10% C49-50, C53-54
1 0027267003 CAP MPF .022uF 100V 10% C26
3 0027270003 CAP MPF .033uF 100V 10% C13-14, C37
6 0027272003 CAP MPF .047uF 63V 10% C12, C25, C46, C65, C67-68
1 0027275003 CAP MPF .068uF 100V 10% C7
2 0052003003 CAP MPF .1uF 250V 10% C69-70
1 0053860000 CAP MPF .1uF 250VAC 20% C77
2 0027278003 CAP MPF .1uF 63V 10% C28, C58
6 0027281003 CAP MPF .22uF 63V 10% C6, C19-20, C35, C64, C66
1 0027283003 CAP MPF .33uF 63V 10% C48
2 0027286003 CAP MPF .47uF 63V 10% C5, C63
1 0030950003 CAP PFF RDL .022uF 50V 5% C23
1 0030953003 CAP PFF RDL .039uF 50V 5% C22
2 0027947000 CONTROL SNAPIN 100k 30C
R27, R46 drive, ch2 treble
1 0027945000 CONTROL SNAPIN 100k B
R34 ch2 volume
1 0027949000 CONTROL SNAPIN 250k 30C
R45 ch2 bass
1 0027940000 CONTROL SNAPIN 50k 15A
R11 ch1 bass
4 0027941000 CONTROL SNAPIN 50k B
R10, R17, R41, R59 ch1 treble, ch1 volume,
ch2 mid, reverb
1 0054390000 CONTROL SNAPIN 5k 15A
R12 ch1 middle
