Fender Frontman 25R Service Manual

FRONTMAN 25
SPECIFICATIONS
Product Release No.: PR 356 (This is not a model number)
Part Number: 120V Version: 22-1502-000
240V Aust: 22-1532-000
230V UK: 22-1542-000
230V Euro: 22-1562-000
Power Specification: 120V Version: 120 V AC, 60 Hz, .92A max
230V Version: 230 V AC, 50 Hz, 0.5A max
Input Impedance: > 1 megohm
Nominal Input Level: 100 mV
Power Output: 25 Watts RMS
Speaker: One 8 Ω special design 10" speaker
Dimensions: Height: 15-1/2" (39.4 cm)
Width: 17" (43.2 cm)
Depth: 8-1/2" (30.5 cm)
Weight: 25 lbs. (11.4 kg)
Product specifications are subject to change without notice
FRONTMAN 25
PARTS LIST
NOTE: SHADED ITEMS ARE FOR REFERENCE ONLY
PRINTED CIRCUIT BOARD
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 048352 PCB UNIT "CHAMP 110/FRNTMAN 25R"
2 038689 CAP AE AX .47µF 100V 20% C12,13
4 026517 CAP AE AX 2.2µF 50V 20% C4,33,35,38
3 038691 CAP AE AX 4.7µF 50V 20% C34,47,48
1 038693 CAP AE AX 47µF 16V 20% C37
3 025960 CAP AE AX 22µF 16V 20% C6,7,29
2 028471 CAP AE RDL 47µF 50V 20% C45,46
2 033607 CAP AE RDL 2200µF 35V 20% C43,44
2 039255 CAP CA 10pF 100V 5% C3,14
1 038873 CAP CA 22pF 100V 5% C24
1 038698 CAP CA 47pF 100V 5% C27
2 038699 CAP CA 100pF 100V 5% C22,36
1 038701 CAP CA 470pF 50V 5% C11
1 038874 CAP CA 560pF 50V 5% C15
2 039268 CAP CA 4700pF 50V 5% C1,2
3 027278 CAP MPF RDL .1µF 63V 10% C39,40,41
1 033596 CAP MPF RDL .068µF 100V 10% C26
2 027286 CAP MPF RDL .47µF 63V 10% C30,42
2 033580 CAP PFF RDL .0022µF 100V 10% C5,25
1 033581 CAP PFF RDL .0033µF 100V 10% C19
1 033583 CAP PFF RDL .0047µF 100V 10% C20
1 036234 CAP PFF RDL .015µF 100V 10% C28
1 033590 CAP PFF RDL .022µF 100V 10% C17
4 033591 CAP PFF RDL .033µF 100V 10% C9,10,23,31
5 033592 CAP PFF RDL .047µF 100V 10% C8,16,18,21,32
2 034719 CONTROL SNAP IN 50KB R30,42
1 037323 CONTROL SNAP IN 50K 15A R13
3 037324 CONTROL SNAP IN 100K 30C R20,24,29
1 040552 CONTROL SNAP IN 250K 30C R31
1 028104 BUTTON PUSH SWITCH BLACK (@ S1)
11 006260 DIODE 1N4448 75PRV CR1-11
6 064089 DIODE 1N4003 200PRV CR12-17
2 009165 DIODE ZENER 1N4744 15V 1W 5% CR18,19
10 025802 FASTON TAB MALE .250x.032 PCB MT CP1,2,3,5,6,8-12
2 026000 FASTON TAB MALE .187x .032 CP4,CP7
2 025996 FUSE CLIP PCB .250" & 5mm FUSE (@ XF1)
1 034889 FUSE QA 1-1/4"x1/4" 250V 1AMP F1
1 020786 FUSE QA 20mmX5mm 250V .5AMP F1
2 027408 HEADER .1 CTR 2 CKT SQ PIN P5,6
4 016795 IC DUAL OP AMP TLO72C U1,2,3,4
1 031611 IC DUAL OP AMP µPC4560 U5
1 029912 IC µPC1188H 20W (POWER AMP) U6
1 031570 JACK PHONE PCB STEREO PREMIUM J4
2

Fender Frontman 25R Specifications

General

Power Output	25 Watts
Channels	2 (Normal and Drive)
Reverb	Yes
Type	Solid State
Speaker	10" Fender Special Design Speaker
Inputs	1/4" Instrument Input
Outputs	1/4" Headphone Jack
Controls	Gain, Volume, Treble, Bass, Reverb
Footswitch	Optional (for Drive channel)
