FRONTMAN 25
PRINTED CIRCUIT BOARD ASSEMBLY
CONTINUED
QTY PART # DESCRIPTION REFERENCE DESIGNATION
3 037036 JACK PHONE PCB MONO PREMIUM J1,2,3
13 020888 JUMPER WIRE 22GA .5x.175 W1-13
2 026043 JUMPER WIRE 18GA .8x.175 JP1,2
2 028039 LED 5x5mm RED SLB-55VR3 LD1,2
2 9902202281 LED RED LONG LEAD LUMEX CS02 LD3,4
1 040497 PCB FAB CHAMPION 110
1 024942 RES CF 1/4W 22_ 5% R45
1 029604 RES CF 1/4W 300_ 5% R48
2 024961 RES CF 1/4W 470_ 5% R71,72
1 024965 RES CF 1/4W 1K 5% R7
1 024969 RES CF 1/4W 1.5K 5% R73
1 024971 RES CF 1/4W 2.2K 5% R12
1 024972 RES CF 1/4W 2.7K 5% R47
3 024973 RES CF 1/4W 3.3K 5% R19,21,40
2 024975 RES CF 1/4W 3.9K 5% R57,63
1 028034 RES CF 1/4W 5.1K 5% R5
1 024979 RES CF 1/4W 6.8K 5% R3
1 025942 RES CF 1/4W 7.5K 5% R11
1 024980 RES CF 1/4W 8.2K 5% R18
3 024981 RES CF 1/4W 10K 5% R39,49,51
3 024985 RES CF 1/4W 15K 5% R1,6,35
5 024987 RES CF 1/4W 22K 5% R8,16,17,33,44
3 024988 RES CF 1/4W 27K 5% R56,59,60
5 024993 RES CF 1/4W 47K 5% R27,28,32,34,55
1 026507 RES CF 1/4W 62K 5% R64
2 029613 RES CF 1/4W 91K 5% R14,15
1 024997 RES CF 1/4W 100K 5% R68
1 025058 RES CF 1/4W 180K 5% R9,
7 025059 RES CF 1/4W 220K 5% R10,23,25,26,36,37,41
2 025065 RES CF 1/4W 470K 5% R22,38
2 028018 RES CF 1/4W 510K 5% R2,4
1 025067 RES CF 1/4W 680K 5% R58
3 025069 RES CF 1/4W 1M 5% R50,52,54
1 025073 RES CF 1/4W 1.5M 5% R43
1 030737 RES CF 1/2W 5.6_ 5% R61
1 026512 RES CF 1/2W 3.9K 5% R53
1 039128 RES MF 1W 120_ 5% R65
2 027344 RES MF 1W 270_ 5% R69,70
2 028740 RES MF 1W 470_ 5% R66,67
1 028029 RES MF 1W 1.5K 5% R46
FRONTMAN 25
PRINTED CIRCUIT BOARD ASSEMBLY
CONTINUED
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 032958 RES WW BT 5W .33_ 5% R62
2 027638 SCREW TF #4-40x3/8" HWH ZI (U6 MOUNTING)
2 032908 SCREW TF #6-32x3/8" PHP ZI (PCB TO HEATSINK MNT)
2 9904701440 SPACER LED .7x.125 BLUE (@ LD1,2)
1 028091 SWITCH PUSH SLFLK DPDT PC MT S1 (WITHOUT BUTTON)
2 014689 XSTR N-CH JFET J111 TO-92 Q1,2
CHASSIS ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 051217 CHASSIS ASSY FRONTMAN 25R 120V
1 021709 BUSHING SR .437x.062x13/32BLK (@ SPEAKER CABLE)
1 026038 BUSHING SR .625x.062x37/64BLK 100/120V (@ POWER CABLE)
1 010401 BUSHING SR .625x.125x37/64WHT 230V (@ POWER CABLE)
7 033206 BUSHING KNOB SPACER
1 051330 CABLE ASSY 120V 6 FT (100/120V ONLY)
1 050725 CABLE ASSY PWR 230V W/.187 TABS (PWR CABLE 230V EXPORT)
1 040992 CABLE ASSY PWR 5A U.K..187 TABS (PWR CABLE 230V U.K.)
1 036479 CABLE ASSY POWER AUST.W/.187 TABS (240V AUSTRALIA ONLY)
1 051070 CHASSIS FRONTMAN 25R (RAW CHASSIS)
1 026016 FOAM STRIP 1/8"x1"x7" (SPRING TO SLEEVE MOUNT)
1 026017 FOAM STRIP 3/8"x1-1/4"x8"DBL STK (SLEEVE TO CHASSIS MOUNT)
1 034885 HEATSINK BAR RAD/HOT/JAM (HEATSINK COUPLER)
7 026403 KNOB POINTERBLACK 180 DEG
4 069393 NUT #6-32 HEX EXT LOCK (TRANSFORMER MOUNT)
1 051071 PANEL FRONT FRONTMAN 25R
1 051702 PANEL REAR FRONTMAN 25R
1 041397 REVERB SPRING PAN 1BB2E4A
2 028500 SCREW TF #8-32x3/4 HWH SLTD ZI (HEATSINK/ CHASSIS MOUNT)
3 028937 SCREW TF #6-32x5/8" PHP ZI ROLOK (PCB MOUNTING)
1 038900 SCREW TF #6-32x1/4" PHP ZI (@ GROUND LUG)
1 025954 SLEEVE REVERB PAN (CARDBOARD)
3 025936 STAND OFF PCB PUSH ON NYL 3/8"L (PCB MOUNT)
1 025935 SWITCH POWER DPST (100/120V ONLY)
1 039287 SWITCH POWER DPST SEMKO (230V EXPORT ONLY)
1 033613 XFMR POWER "CHAMPION 110" 120V
1 040611 XFMR POWER "CHAMPION 110" 230V
