Fender Frontman 25R Service Manual

FRONTMAN 25
CABINET ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 051069 CABINET ASSY FRONTMAN 25R (COMPLETE CABINET)
4 037344 CLIP SPEAKER (SPEAKER MOUNT)
4 026566 CORNER 2 HOLE W/TAB NI (BOTTOM FRONT, TOP REAR)
4 029071 CORNER NOTCHED NI (BOTTOM REAR)
1 051073 GRILLE ASSY FRONTMAN 25R
1 025883 HANDLE SHORT NO LOGO (RUBBER ONLY. NO INSERT)
1 032524 HANDLE INSERT (SPRING STEEL)
2 025395 HANDLE CAP 1 HOLE NI (DWG 17240) (HANDLE MOUNT)
1 029906 NAMEPLATE FENDER GENERIC SMALL (LOGO)
8 021972 NUT T #10-32x3/4" STR 3 PRNG BLX (HANDLE/SPEAKER MOUNT)
4 022277 SCREW M #10-32x1-1/2 OHP NI (HANDLE MOUNT)
2 018113 SCREW SMA #4x1/2" OHP BLX (LOGO MOUNT)
4 026577 SCREW M #10-32x1" PHP BLX (SPEAKER MOUNT)
2 026800 SCREW SMAB #8x1-3/4" OHP BLX (GRILLE MOUNT)
4 036199 SCREW M #8-32x1-3/16" OHP BLX WX (CHASSIS MOUNT)
14 026571 SCREW CORNER MOUNTING
1 036502 SPEAKER 10" 8_
4 029527 WASHER FNSH #8-5/8" FLNGD BLX WX (CHASSIS/GRILLE MOUNT)
FOOTSWITCH ASSEMBLY
(OPTIONAL)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 028890 FOOTSWITCH ASSY 1 BUTTON F/LOGO (COMPLETE FOOTSWITCH)
1 006260 DIODE 1N4448 75PRV CR1
1 037036 JACK PHONE PCB MONO PREMIUM J1
1 028039 LED 5x5mm RED SLB-55VR3 LD1
1 028714 SWITCH PUSH SPDT S1
MISCELLANEOUS
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 051154 OWNERS MANUAL FRONTMAN 25R
1 040502 SCHEMATIC REDUCED CHAMPION 110/FRONTMAN 25R W/SERVICE DIAGRAM
4

Fender Frontman 25R Specifications

General

Power Output	25 Watts
Channels	2 (Normal and Drive)
Reverb	Yes
Type	Solid State
Speaker	10" Fender Special Design Speaker
Inputs	1/4" Instrument Input
Outputs	1/4" Headphone Jack
Controls	Gain, Volume, Treble, Bass, Reverb
Footswitch	Optional (for Drive channel)
