Fender G-DEC Junior - Specifications

G-DEC
®
Jr
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY section above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded + ** Both a unique Fender® part and a Safety Requirement part as defined above.
9
PARTS LIST: END ITEM ASSEMBL
Y
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 REF *CABINET ASSY G-DEC® Jr
5 REF SCREW M) 4X30 BLK T/H @ CABINET BACK
1 REF SPEAKER 8" 8 OHM G-DEC® Jr
4 REF NUT FLANGE M) 4 ZNP @ SPEAKER
1 0047248000 **CORD PWR W/IEC CONN DOM 120V ONLY
- 0047249000 **CORD PWR W/IEC CONN 230V UK 230V UK ONLY
- 0047250000 **CORD PWR W/IEC CONN 240V 240V AUS ONLY
- 0047251000 **CORD PWR W/IEC CONN 230V 230V EUR ONLY
0057674000 **CORD PWR W/IEC CONN 230V ARG 230V ARG ONLY
-
0053997000
**CORD PWR W/IEC CONN 100V JPN
100V JPN ONLY
1 0072802000 *BADGE G-DEC®
2 REF SCREW T) 2.1X10 NIP R/H @ BADGE
1 0051043000 *NAMEPLATE FENDER GENERIC
4 0036500000 ESCUTCEHON PINS @ NAMEPLATE
1 REF MANUAL OWNERS G-DEC® Jr
5 REF SCREW NO. 8 U32X30 BLK O/H @ CHASSIS TOP AND REAR
3 REF SCREW M 3.5X10 BLK T/H @ CHASSIS REAR
4 REF WASHER BLK FINISHING TYPE @ CHASSIS
1 0037121000 HANDLE RIBBED 9 1/4"
2 0032524000 HANDLE STRAP METAL INSERT
2 0025395000 HANDLE CAPS - NICKEL
2 REF M)4X32 NIP O/H @HANDLE
4 REF FOOT RUBBER 18X10
4 REF T)2.1X8 BLK R/H @ FEET
