10
Specifications
MODEL: All Models
INPUT IMPEDANCES: 1MΩ (Input) 10kΩ (Aux In)
INPUT SENSITIVITY: (For full power at 100Hz, with Gain/Master at "10", and tone controls at "0") 25mVrms (Input) / 250mVrms (Aux In, both channels driven)
TONE CONTROLS: BASS: ±15dB @ 80Hz LOW-MID: ±12dB @ 280Hz
HIGH-MID: ±12dB @ 1.2kHz TREBLE: ±15dB @ 10kHz
SHAPE FILTER: BRIGHT: +13dB @ 10kHz CONTOUR: +1dB @ 80Hz, -13dB @ 670Hz, +2dB @ 8kHz
VINTAGE
: Dynamic compression (-9dB max) with low pass (-6dB/oct) @ 400Hz
EFFECTS LOOP IMPEDANCES:
SEND: 1kΩ (balanced)
RETURN:
22kΩ (balanced)
LINE OUT:
OUTPUT IMPEDANCE:
3.3kΩ (balanced)
MAXIMUM OUTPUT:
+3.75dBU
HEADPHONE OUTPUT: 280mW into 32Ω/Channel
MODEL: Rumble 40 Rumble 100
POWER REQUIREMENT: 110W Max / 45W Typical 310W Max / 50W Typical
POWER AMP OUTPUT:
40
W into
8
Ω
100
W into
8
Ω
SPEAKERS: One 10 in (25.4 cm), 8Ω, Special Design Ceramic One 12 in (30.5 cm), 8Ω, Eminence® Ceramic
MODEL: Rumble 200 Rumble 200 HEAD
POWER REQUIREMENT: 400W Max / 70W Typical 400W Max / 70W Typical
POWER AMP OUTPUT:
140
W into
8
Ω
140
W into
8
Ω
200
W into
4
Ω
200
W into
4
Ω
SPEAKERS: One 15 in (38.1 cm), 8Ω, Eminence® Ceramic N/A
Piezo Tweeter
MODEL: Rumble 500 Rumble 500 HEAD
POWER REQUIREMENT: 950W Max / 150W Typical 950W Max / 150W Typical
POWER AMP OUTPUT:
350
W into
8
Ω
350
W into
8
Ω
500
W into
4
Ω
500
W into
4
Ω
SPEAKERS: Two 10 in (25.4 cm), 16Ω, Eminence® Ceramic N/A
Piezo Tweeter
Specifications are subject to change without notice. Visit www.fender.com for additional product information.
Block Diagram
ENGLISH
