PARTS LIST
POWER AMP
PRINTED CIRCUIT BOARD ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 033310 PCB ASSY POWER AMP (120V)
1 033311 PCB ASSY POWER AMP (220V/240V)
1 033312 PCB ASSY POWER AMP (100V)
1 032927 PCB SR6520P/SR8520P PWR AMP (BLANK BOARD)
8 028459 CAP AE RDL 50V 2.2uF 20% C1,2,5,24,26-29
2 028460 CAP AE RDL 50V 4.7uF 20% C3,10
2 028471 CAP AE RDL 50V 47uF 20% C22,23
3 025787 CAP AE RDL 16V 100uF 20% C6,11,12 (NON POLAR)
2 028494 CAP AE RDL 35V 1000uF 20% C16,17
2 025786 CAP AE RDL 80V 6800uF 20% C14,15
1 025970 CAP CD 1KV 5pF 10% C7
2 025982 CAP CD 1KV 68pF 10% C8,9
1 069724 CAP CD 1KV 100pF 10% C30
1 024854 CAP MPF 400V .1uF 10% C13
5 027278 CAP MPF 63V .1uF 10% C18-21,25
1 027257 CAP MPF 100V .0022uF 10% C4
6 064089 DIODE 1N4003 CR22-25,28,29
24 006260 DIODE 1N4448 SIGNAL BENT CR1,3-13,16,17,26,27,30-37
2 020534 DIODE 1N5402 RECTIFIER 200V CR20,21
4 025821 DIODE HV FDH400 SWITCHING CR14,15,18,19
1 031019 DIODE ZENER 1N5245B .5W 15V CR2
1 027329 DIODE ZENER 1N5228B 3.9V CR38
2 025996 FUSE CLIP PCB .250 & 5mm XF1 (100V/120V)
4 020775 FUSE CLIP PCB 5mm XF2,3 (220V/240V)
1 028330 FUSE QA 1-1/4X1/4 250V 10AMP F1 (100V/120V)
1 020798 FUSE QA 5mm 250V 5AMP F1 (220V/240V)
2 020789 FUSE QA 5mm 250V 1AMP F2,3 (220V/240V ONLY)
1 027416 HEADER .1 CTR 8 CKT SQ PIN P1
1 031269 HEATSINK SR SERIES (MAIN HEATSINK)
2 025796 HEATSINK TO-220 U3,4
1 027404 IC 3080EA OTA U2
1 016795 IC DUAL OP AMP TLO72C U1
1 027387 INDUCTOR AIR CORE RDL 2.5uH L1
PARTS LIST
POWER AMP
PRINTED CIRCUIT BOARD ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
4 017974 MICA PAD TO-220 Q14-17
8 074211 MICA PAD TO-3 PRE-GREASED Q18-25
1 69904200200 NUT PEM 6-32 AT Q18-25
1 025674 POT TRIM LINEAR 30% 1.5K R20 (Bias adjust}
1 013562 REGULATOR +15V MC7815CT U3
1 013564 REGULATOR -15V MC7915 U4
1 024952 RES CF 1/4W 100ohm 5% R67
2 024956 RES CF 1/4W 220ohm 5% R21,22
2 024961 RES CF 1/4W 470ohm 5% R27,31
1 024963 RES CF 1/4W 680ohm 5% R57
7 024965 RES CF 1/4W 1K 5% R3,6,14,25,32,54,64
1 024967 RES CF 1/4W 1.2K 5% R19
4 024971 RES CF 1/4W 2.2K 5% R12,13,16,17
2 024975 RES CF 1/4W 3.9K 5% R18,52
1 024977 RES CF 1/4W 4.7K 5% R62
1 025942 RES CF 1/4W 7.5K 5% R10
6 024981 RES CF 1/4W 10K 5% R47,49,51,63,66,68
1 024985 RES CF 1/4W 15K 5% R55
2 024987 RES CF 1/4W 22K 5% R1,61
4 024988 RES CF 1/4W 27K 5% R7,15,28,29
2 024989 RES CF 1/4W 33K 5% R2,60
1 024993 RES CF 1/4W 47K 5% R59
5 024997 RES CF 1/4W 100K 5% R46,48,50,53,56
1 024998 RES CF 1/4W 120K 5% R65
1 024999 RES CF 1/4W 150K 5% R58
2 025069 RES CF 1/4W 1M 5% R4,5
4 033205 RES MF 1/4W 15ohm 5% R23,24,33,34 (fused)
4 036960 RES MF 1/4W 47ohm 5% R8,9,26,30 (fused)
1 031900 RES CF 1/2W 15K 5% R11
1 027627 RES FILM 1W 10ohm 5% R45
2 027628 RES FILM 2W 47ohm 5% R43,44
8 032958 RES WW 5W .33ohm 10% R35-42
1 032905 RES WW 10W 400ohm 5% R69
2 027638 SCREW TF 4-40X3/8" HWH ZI (AT U3,4)
